Part Number: 9291468 09/17 25
Section 4 Maintenance
5. If carrier is riding too high, you need to remove springs.
With carrier all the way to the top, gently disengage
one spring at a time, unhooking bottom loop out of
carrier bracket. Remove as many springs as necessary.
If carrier is riding too low, you need to add springs. With
carrier all the way to the top, gently engage one spring
at a time by hooking bottom loop of spring into carrier
bracket. Add as many springs as necessary.
Remove Or Add
Springs As Needed
Remove Or Add Springs
6. When finished, put elevator housing back in unit
(except on models LT) and put stainless steel load tray
back on elevator housings. Load unit to test dispensing
level. If spring adjustment does not position carrier
properly, repeat procedure #5 trying different springs.
If this does not work, a different set of springs may be
required.
7. If level is appropriate, put front panels back on and
tighten retainer.
,
Caution
Dispenser should not be operated with front panels off
elevator housing.
NOTE: When adjusting the elevators make sure each have
the same number and size of springs connected to the
carrier on both sides. This will prevent the load tray from
binding.
Non-Marring Rod Installation
1. If applicable disconnect any power before servicing
equipment.
2. If applicable remove dish dispenser from base.
3. Remove Spinning Head (S/S base that the plates sit on).
4. Disconnect and remove all springs from outer body
and from Wire Head.
5. Bend back tabs if necessary.
Tab
6. Remove Wire Head.
Springs
Wire Head
