Page 7
Reduced gas flow rate setting for taps
1. Ignite the burner that is to be adjusted and
turn the knob to the reduced position.
2. Remove the knob from the gas tap.
3. Use an appropriately sized screwdriver to
adjust the flow rate adjustment screw. For
LPG (Butane - Propane) turn the screw
clockwise. For natural gas, you should turn
the screw counter-clockwise once. The
normal length of a straight flame in the
reduced position should be 6-7 mm
4. If the flame is higher than the desired position,
turn the screw clockwise. If it is smaller turn
anticlockwise.
5. For the last control, bring the burner to both
the high-flame and reduced positions and
check whether the flame is on or off.
Depending on the type of gas tap used in your
appliance the adjustment screw position
may
vary.
Gas conversion
In order to have the appliance's gas type
changed, all the injectors must be changed and
the flame adjustment for all valves must be set
at the reduced flow rate position.
Changing the injectors
1. Take off burner cap and burner body.
2. Unscrew injectors by turning them
counterclockwise.
3. Fit new injectors.
4. Check all connections for secure fitting and
tightness.
The flames should be blue and burn
smoothly. If the flames appear
yellowish, check that the burner cap
is seated correctly or clean the
burner. Switch off the gas and let
burner cool before touching it.
Routing of the gas hose
Before connecting the gas hose, make sure that
the gas hose outlet behind the product is in the
same direction as the hose outlet
3
3
X
X
X
1 Flame failure device (model dependent)
2 Spark plug
3 Injector
4 Burner
DANGER Risk of explosion or
poisoning by unprofessional
installation. Gas conversion must
only be carried out by a registered
installer.
Unless there is an abnormal
condition, do not attempt to remove
the gas burner taps. You must call
an authorised service agent if it is
necessary to change the taps.
New injectors have their position
marked on their packing or refer to
the Injector table.
If the gas type of the appliance is
changed, then the sticker that is
currently on the underside of the
appliance that reads “LPG 2,8
kPa” must be covered by sticking
the sticker “NG 2,0 kPa” over it.
