Page 6
Important information
Upon completion of the installation ensure that you
are familiar with the following:
a) The position of the isolation or shut-off valve in
the gas supply line to the appliance.
b) The requirements for safe operation of the
appliance
Ensure that pipe clamps are tightened correctly
and are of a good quality.
• Flexible hose
Any hose that is used to connect the stove to
the gas system shall comply with SANS 1156-2
or BS 3212.
• Gas cylinder - Not supplied.
For best results we recommend that gas cylin-
ders with a minimum capacity of 9kg be used.
• Regulator - Not supplied.
A 2.8-3.0 kPa LPG gas regulator which com-
plies with SANS 1237 must be used.
Failure to comply with the above will render the
warranty invalid.
Note: Your invoice is required in the event of
you wishing to make a warranty claim.
Connecting the gas hose
• Have your appliance connected so that it will be
close to the gas connection. Ensure that there
is no gas leakage.
• Gas bottles should be located outdoors in a
suitable ventilated lock-up.
• The connecting hose to be used must not be
longer than 200 cm in length.
• Fit the clamp to the hose. Soak one end of the
hose (15 mm inner diameter) into hot water for
60 seconds to soften, then slip the softened end
of the hose completely onto the sharp hose tip
of the appliance.
• Secure the hose by tightening the hose clamp.
• Repeat the same procedure for the other end of
the hose by securing it to the regulator on the
gas bottle to complete the gas cylinder
connection.
• Always check for gas leaks after installation and
whenever a new or refilled gas bottle is used for
the first time.
Leakage control at the connection point
• Ensure that the control knobs on the control
panel are in the OFF position.
• Open the valve on the Gas bottle.
• Using a small paint brush, apply some soapy
water to all the connections.
• If there is a leak, bubbles will appear.
• If this occurs, close the gas bottle valve .
• Check and tighten the connections
immediately.
• Repeat the procedure to ensure that there are
no further leaks.
1. Hose tip-LPG
2. Hose tip-NG
3. Safety hose
4. O-ring (gasket)
5. Clamp
Manifold
Caution: Never use a naked flame
to check for gas leaks.
DANGER Risk of explosion by
damage of the safety tube!
The safety tube must not be
clamped, bent or come into contact
with hot parts of the appliance.
DANGER Risk of explosion and
suffocation! LPG bottles must not
be stored in the house.
Nut to be
tightened with Max
50 N.m Torque
