INSTALLATION & SERVICE MANUAL FOR PROFESSIONALS
Appendix: Technical data
en
Specication Abbr. Unit HCV 300 HCV 500 HCV 700
Operating range (min. @ 50Pa -
max. @ 100Pa)
V
m/h
50 to 180 80 to 300 80 to 450
Reference ow (@ 50Pa) V
REF
m/h 126 210 315
Performance
Temperature eciency in accor-
dance with EN13141-7
h
SUP
%
from 85%
to 86%
from 85%
to 88%
from 85%
to 88%
Specic power consumption in
accordance with EN13141-7
SEL/SPI m/h 0.28 0.21 0.22
Leakage (external and internal)
in accordance with EN13141-7
- % < 2 (Class A1)
Filters in accordance with
ISO16890 / EN779
- -
ISO Coarse 75% / G4
(optional: ePM1 55% / F7)
Ambient temperature for instal-
lation
t
SURR
°C from +12 to +50
Outdoor temperature without
pre-heater installed
t
ODA
°C from -12 to +50
Outdoor temperature with pre-
heater installed
t
ODA
°C from -25 to +50
Maximum absolute humidity of
extract air
x g/kg 10
Cabinet:
Exterior dimensions without wall
brackets)
W x H x D mm
600 x 1000
x 430
700 x 1050
x 603
700 x 1050
x 750
Spigots/duct connections Ø mm
125 - fe-
male
160 - fe-
male
200 - fe-
male
Weight m kg 36 49.5 70
Heat conductivity of the
polystyrene insulation
l
W/(mK) 0.031
Heat transition gures -
polystyrene insulation
U W/(m
2
K) < 1
Fire class - polystyrene insulation - -
DIN 4102-1 Class B2
EN 13501 Class E
Drainage hose Ø/length " / m 3/4” – 1m
Cabinet colour RAL - 9016
Electrical
Voltage U V 230
Max. power consumption (with-
out/with preheater)
P W 170/870 170/1370 234/1834
Frequency f Hz 50
IP class -
-
21
* The use of the preheating coil is recommended at outdoor temperatures below -3°C to
ensure balanced operation
Data sheet
HCV 300/500/700
