Specification table for non catalogue numbers of LS Steering Units
Fill in your company data and place x’s in the table where appropriate, then send to your Danfoss Sales
Organization.
Your
company
Name Vehicle Potential pcs/year Completed by Date
Steering unit
type
OSPC OSPF OSPD OSPL OSPBX OSPCX OSPLX
Reaction type LS ( Non-reaction) LSR (Reaction: only OSPC, OSPD)
Load Sensing
type
Static (Only OSPC, OSPL, OSPBX, OSPCX, OSPLX) Dynamic
DP, cm³/rev
OSPC LS
OSPF LS
40 50 60 70 80 100 125 160 185 200 230 250 315 400
DP, cm³/rev
OSPC LSR
40 50 60 70 80 100 125 160 185 200
DP, cm³/rev
OSPD LS
60/185 60/220 60/260 70/195 70/230 70/270 70/385 100/200 100/260 100/300 125/285 125/325 125/440
DP, cm³/rev
OSPD LSR
60/185 60/220 70/195 70/230 100/200
DP, cm³/rev
OSPL, OSPLX
520 630 800 1000 1200 (only OSPL)
DP, cm³/rev
OSPBX LS
OSPCX LS
160 200 250 315 400
Port threads
OSPC, OSPF
G1/2 G1/2- S** M18 × 1.5 - O* + S** 3/4-16 UNF - O* for OLSA (only OSPC)
Port threads
OSPD
G1/2- S** M18 × 1.5 - O* + S** 3/4-16 UNF - O*
Port threads
OSPL, OSPLX
G1/2 3/4-16 UNF - O* For OPVL and without RV (LS = 7/16 - 20
UNF)
For OVPL and with RV (LS = G 1/4)
Relief
valve***
bar
70 80 90 100 110 120 140 170 190 200 210 no relief valve
Shock valves
bar
160 180 200 225 240 280 no shock valves
Suction
valves
Yes No
Check valve
in LS
Yes (Only for OSPC dynamic and OSPD) No (Only for OSPC, OSPF and OSPL)
Neutral
setting
springs
Soft:
0.5 - 1.8 Nm in normal steering situations
Standard:
0.8 - 3 Nm in normal steering situations
Strong:
1.5 - 4 Nm in normal steering situations
Unit black
painted
Yes No
Technical Information
OSPB/C/F/D/L LS Steering Units, OLS Priority Valves, OSQ Flow Amplifiers
LS Steering Units OSPB, OSPC, OSPF, OSPD, OSPL
©
Danfoss | April 2021 BC152886483962en-001003 | 21
