DP = Displacement, RV = Pilot pressure relief valve.
O*: O-ring chamfer on port connections.
S**: Spot face around port connections (can not be used in connection with OVR angular block).
RV*** see Technical data for limitation in maximum pressure depending on displacements.
Types not mentioned with port connections in the table above, are only available in the version(s) stated
in the code number tables.
An alternative way to specify a variant is to state an existing code number and add the modifications, you
would like to have implemented in the basic steering unit.
Code number of basic steering unit: __________________________________________________
Requested modifications: ___________________________________________________________
Technical data
Common data, refer to General Steering Components Technical Information, BC152886484183.
Displacement, flow and pressure: OSPB LS, OSPC LS, OSPC LSR
OSPB LS, OSPC LS, OSPC LSR
Steering unit Displacement
cm³/rev
[in³/rev]
Rated oil
flow
*
l/min
[US gal/min]
Max. pressure, bar (psi)
System
pressure
**
P-T port
pressure
T,
absolute
port
pressure
L-T/R-T
port
pressure
OSPC 40 LS Static 40 [2.44] 4 [1.06] 140 [2030] 40 [580] 280 [4061]
OSPB/OSPC 50 LS Static 50 [3.05] 5 [1.32]
OSPC 60 LS Static 60 [3.66] 6 [1.58]
OSPC 70 LS Static 70 [4.27] 7 [1.85] 175 [2538]
OSPB/OSPC 80 LS Static 80 [4.88] 8 [2.11]
OSPB/OSPC 100 LS Static 100 [6.10] 10 [2.64]
OSPB/OSPC 125 LS Static 125 [7.63] 13 [3.43] 210 [3045]
OSPB/OSPC 160 LS Static 160 [9.76] 16 [4.23]
OSPC 185 LS Static 185 [11.29] 19 [5.02]
OSPB/OSPC 200 LS Static 200 [12.20] 20 [5.28]
OSPC 230 LS Static 230 [14.03] 23 [6.07]
OSPC 250 LS Static 250 [15.25] 25 [6.60]
OSPB/OSPC 315 LS Static 315 [19.22] 32 [8.45]
OSPB/OSPC 400 LS Static 400 [24.41] 40 [10.57]
*
Rated flow at 100 rpm.
**
Any OSPB/C LS Static can withstand 210 bar in maximum system pressure. However, OSPB/C with small gear wheel
set and high pressure will have relatively high slippage values.
Technical Information
OSPB/C/F/D/L LS Steering Units, OLS Priority Valves, OSQ Flow Amplifiers
LS Steering Units OSPB, OSPC, OSPF, OSPD, OSPL
22 |
©
Danfoss | April 2021 BC152886483962en-001003
