shock valves
•
suction valves
OSPL 1200 LS in the table below has strong neutral setting springs, see Specification Table for Non
Catalogue Numbers of LS Steering Units
Steering unit
Code numbers Valve settings Weight
kg [lb]
Connections
US version for OLS
3/4 - 16 UNF - O
*)
CF: 11/16 - 12 UN
7/16 - 20 UNF - O
*)
* + S
**)
Shock valves
bar [psi]
OSPL 1200 LS 150-7175 280 [4061] 11 [24.25]
*)
O-ring chamfer on port connections
**)
Spot face around port connection
If you require other displacements or other valve setting, please fill in the order form in the Specification
Table for Non Catalogue Numbers of LS Steering Units and contact the Danfoss Sales Organization.
OSPBX and OSPLX load sensing static steering units for OSQ static
OSPBX LS and OSPLX LS Static steering units in the table below have no valve functions.
OSPBX LS in the table below have all standard neutral setting springs, see Specification Table for Non
Catalogue Numbers of LS Steering Units
OSPLX LS in the table below have all strong neutral setting springs, see Specification Table for Non
Catalogue Numbers of LS Steering Units
Steering unit Code numbers Weight
kg [lb]
Connections
European version
G 1/2
G 1/4 - S
**)
US version
3/4-16 UNF - O
*)
7/16-20 UNF - O
*)
* + S
**)
OSPBX 160 LS 150-1082 150-1078 5.6 [12.35]
OSPBX 200 LS 150-1083 150-1079 5.8 [12.79]
OSPBX 315 LS 150-1084 150-1080 6.2 [13.67]
OSPBX 400 LS 150-1085 150-1081 7.0 [15.43]
OSPLX 520 LS 150-7170 150-7173 8.1 [17.86]
OSPLX 630 LS 150-7171 150-7174 8.4 [18.52]
OSPLX 800 LS 150-7172 150-7155 8.8 [19.40]
**)
Spot face around port connection
*)
O-ring chamfer on port connections
OSPCX load sensing dynamic steering units for OSQ dynamic
OSPCX LS Dynamic steering unit in the table below incorporates the following valve function:
•
pilot pressure relief valve
See
Specification Table for Non Catalogue Numbers of LS Steering Units
If you require other displacements or other valve setting, please fill in the order form in the Specification
Table for Non Catalogue Numbers of LS Steering Units and contact the Danfoss Sales Organization.
Technical Information
OSPB/C/F/D/L LS Steering Units, OLS Priority Valves, OSQ Flow Amplifiers
LS Steering Units OSPB, OSPC, OSPF, OSPD, OSPL
20 |
©
Danfoss | April 2021 BC152886483962en-001003
