OSPL load sensing static non-reaction steering units
OSPL LS Static steering units have no valve functions.
OSPL LS in the three tables below have all strong neutral setting springs, see Specification Table for Non
Catalogue Numbers of LS Steering Units
Steering unit Code numbers Weight
kg [lb]
Connections
European version
for OLS
G 1/2
G 1/4 - S
**)
US version for OLS
3/4-16 UNF - O
*)
*
7/16-20 UNF - O* +
S
**)
US version for OLS
and OVPL LS - port
7/16-20 UNF - O* +
S
**)
OSPL 520 LS 150-7169 150-7167 150-7168 8.1 [17.86]
OSPL 630 LS 150-7107 150-7164 150-7113 8.4 [18.52]
OSPL 800 LS 150-7108 150-7165 150-7114 8.8 [19.40]
OSPL 1000 LS 150-7110 150-7166 150-7115 10.0 [22.05]
**)
Spot face around port connection
*)
O-ring chamfer on port connections
OSPL load sensing dynamic non-reaction steering units
OSPL LS Dynamic steering units in the table below have no valve functions.
Steering unit Code numbers Weight
kg [lb]
Connections
US version for OLS
3/4-16 UNF - O
*)
7/16-20 UNF - O
*)
* +S
**)
OSPL 520 LS 150-8243 8.1 [17.86]
OSPL 630 LS 150-8212 8.4 [18.52]
OSPL 800 LS 150-8213 8.8 [19.40]
OSPL 1000 LS 150-8214 10.0 [22.05]
*)
O-ring chamfer on port connections
**)
Spot face around port connection
OSPL LS Dynamic steering units in the table below incorporate all the following valve function:
•
pilot pressure relief valve
Steering unit Code numbers Valve settings Weight
kg [lb]
Connections
European version
for OLS and OVPL
LS: G 1/4 - S
**)
Relief valve
bar [psi]
OSPL 520 LS 150-8244 170 [2465] 8.1 [17.86]
OSPL 1000 LS 150-8245 10.0 [22.05]
**)
Spot face around port connection
If you require other displacements or other valve setting, please fill in the order form in the Specification
Table for Non Catalogue Numbers of LS Steering Units and contact the Danfoss Sales Organization.
OSPL 1200 LS Dynamic steering unit in the table below incorporate all the following valve function:
Technical Information
OSPB/C/F/D/L LS Steering Units, OLS Priority Valves, OSQ Flow Amplifiers
LS Steering Units OSPB, OSPC, OSPF, OSPD, OSPL
©
Danfoss | April 2021 BC152886483962en-001003 | 19
