OSPC load sensing static non-reaction steering unit
OSPC LS Static steering units in the table below incorporate all the following valve functions:
•
check valve in P-port
•
pilot pressure relief valve
•
shock valves
•
suction valves
OSPC LS in the table below have all standard neutral setting springs, see Specification Table for Non
Catalogue Numbers of LS Steering Units
Steering unit Code numbers Valve settings Weight
kg [lb]
Connections Relief
valve
bar [psi]
Shock
valve
bar [psi]
European
for OLS
G 1/2
G 1/4 - S
**)
European
and
US version
for OLSA
US version for OLS
3/4-16 UNF - O
*)
7/16-20 UNF - O
*)
+ S
**)
OSPC 80 LS 150-1230 150-1188 150-1222 170
[2465]
225
[3263]
5.3 [11.68]
OSPC 100 LS 150-1231 150-1189 150-1221 5.4 [11.90]
OSPC 125 LS 150-1232 150-1190 150-1220 5.5 [12.13]
OSPC 160 LS 150-1233 150-1191 150-1219 5.6 [12.35]
OSPC 200 LS 150-1234 150-1192 150-1218 5.8 [12.79]
OSPC 315 LS 150-1235 - 150G6091 6.2 [13.67]
OSPC 400 LS 150-1240 - - 7.0 [15.43]
*)
O-ring chamfer on port connections
**)
Spot face around port connections
If you require other port connections, valve combinations and/or other valve settings or other
displacements, please fill in the order form in the Specification Table for Non Catalogue Numbers of LS
Steering Units and contact the Danfoss Sales Organization.
OSPC load sensing dynamic non-reaction steering units
OSPC LS Dynamic steering units in the table below incorporate all the following valve functions:
•
check valve in P-port
•
pilot pressure relief valve
•
shock valves
•
suction valves
•
check valve in LS-line for all OSPC LS Dynamic up to and including 200 cm³/rev
OSPC LS in the table below have all standard neutral setting springs, see Specification Table for Non
Catalogue Numbers of LS Steering Units
Technical Information
OSPB/C/F/D/L LS Steering Units, OLS Priority Valves, OSQ Flow Amplifiers
LS Steering Units OSPB, OSPC, OSPF, OSPD, OSPL
16 |
©
Danfoss | April 2021 BC152886483962en-001003
