Code numbers and weights
OSPB load sensing static non-reaction steering units
OSPB LS Static steering units have no valve functions.
OSPB LS in the table below have all standard neutral setting springs, see
Specification Table for Non
Catalogue Numbers of LS Steering Units
Steering unit Code Numbers Weight
kg [lb]
Connections
European version for OLS
G 1/2
G 1/4 - S
**)
US version for OLS
3/4-16 UNF - O
*)
7/16-20 UNF - O
*)
+ S
**)
OSPB 50 LS - 150G6085 5.2 [11.46]
OSPB 80 LS - 150G6086 5.3 [11.68]
OSPB 100 LS - 150G6087 5.4 [11.90]
OSPB 125 LS - 150G6088 5.5 [12.13]
OSPB 160 LS - 150G6089 5.6 [12.35]
OSPB 200 LS 150-0103 150G6090 5.8 [12.79]
OSPB 315 LS 150-0104 150-0116 6.2 [13.67]
OSPB 400 LS 150-0105 150-0117 7.0 [15.43]
*)
O-ring chamfer on port connections
**)
Spot face around port connection
Valve blocks OVP and OVR can be mounted on all of the OSPB steering units from the above table.
OSPB load sensing dynamic non-reaction steering units
OSPB LS Dynamic steering units have no valve functions.
OSPB LS in the table below have all standard neutral setting springs, see Specification Table for Non
Catalogue Numbers of LS Steering Units
Steering unit Code Numbers Weight
kg [lb]
Connections
US version for OLS
3/4-16 UNF - O
*)
7/16-20 UNF - O
*)
+ S
**)
OSPB 50 LS 150-8204 5.2 [11.46]
OSPB 80 LS 150-8205 5.3 [11.68]
OSPB 100 LS 150-8206 5.4 [11.90]
OSPB 125 LS 150-8207 5.5 [12.13]
OSPB 160 LS 150-8208 5.6 [12.35]
OSPB 200 LS 150-8209 5.8 [12.79]
OSPB 315 LS 150-8210 6.2 [13.67]
OSPB 400 LS 150-8211 7.0 [15.43]
*)
O-ring chamfer on port connections
**)
Spot face around port connection
Valve blocks OVP and OVR can be mounted on all of the OSPB steering units from the above table
Technical Information
OSPB/C/F/D/L LS Steering Units, OLS Priority Valves, OSQ Flow Amplifiers
LS Steering Units OSPB, OSPC, OSPF, OSPD, OSPL
©
Danfoss | April 2021 BC152886483962en-001003 | 15
