Steering unit Code numbers Valve settings Weight
kg [lb]
Connections Relief
valve
bar [psi]
Shock
valve
bar [psi]
European
version for OLS
G 1/2 - S
**)
G 1/4 - S
**)
European and
US version for
OLSA
US version
for OLS
3/4-16 UNF - O
*)
7/16-20 UNF - O
*)
+S
**)
OSPC 50 LS 150-8233 150-8222 150-8215 140
[2030]
200
[2900]
5.2 [11.46]
OSPC 80 LS 150-8234 150-8223 150-8216 170
[2465]
225
[3263]
5.3 [11.68]
OSPC 100 LS 150-8235 150-8224 150-8217 5.4 [11.90]
OSPC 125 LS 150-8236 150-8225 150-8218 5.5 [12.13]
OSPC 160 LS 150-8237 150-8226 150-8219 5.6 [12.35]
OSPC 200 LS 150-8238 150-8227 150-8220 5.8 [12.79]
OSPC 315 LS 150-8239 - 150-8221 6.2 [13.67]
OSPC 400 LS 150-8240 - - 7.0 [15.43]
**)
Spot face around port connections
*)
O-ring chamfer on port connections
If you require other port connections, valve combinations and/or other valve settings or other
displacements please fill in the order form in the Specification Table for Non Catalogue Numbers of LS
Steering Units and contact the Danfoss Sales Organization.
OSPC load sensing dynamic reaction steering units
OSPC LSR Dynamic steering units in the table below incorporate all the following valve functions:
•
check valve in P-port
•
pilot pressure relief valve
•
shock valves
•
suction valves
•
check valve in LS-line
OSPC LSR in the table below have all standard neutral setting springs, see Specification Table for Non
Catalogue Numbers of LS Steering Units
Steering unit Code numbers Valve settings Weight
kg [lb]
Connections
European version for OLS
G 1/2 - S
**)
G 1/4 - S
**)
Relief valve
bar [psi]
Shock valve
bar [psi]
OSPC 80 LSR 150-8241 170 [2465] 225 [3263] 5.3 [11.68]
OSPC 200 LSR 150-8242 5.8 [12.79]
**)
Spot face around port connections (can not be used in connection with OVR angular block)
If you require other port connections, valve combinations, valve settings and/or other displacements,
please fill in the order form in the Specification Table for Non Catalogue Numbers of LS Steering Units and
contact the Danfoss Sales Organization.
OSPF load sensing dynamic non-reaction steering units
OSPF LS Dynamic steering units in the table below incorporate all the following valve functions:
Technical Information
OSPB/C/F/D/L LS Steering Units, OLS Priority Valves, OSQ Flow Amplifiers
LS Steering Units OSPB, OSPC, OSPF, OSPD, OSPL
©
Danfoss | April 2021 BC152886483962en-001003 | 17
