Je bekijkt pagina 5 van 16
5. Initial Configuration
5.1 Mains Power Connection
The AMP-4750 DSP amplifier incorporates a power
factor corrected universal power supply and can be
used with mains input voltage from 100V AC to 240V AC,
50/60Hz. Use the mains cable supplied with the amplifier
and connect it to a mains supply.
Press the front panel power buon to switch on the
amplifier. Aer a short delay the front panel Status
indicator will illuminate green.
5.2 Amplifier Network
Connection
The AMP-4750 DSP amplifier is configured via the DALI
PHANTOM CI AMP CONFIGURATOR interface. Before
the configuration menus can be accessed, the AMP-
4750 DSP amplifier must be either connected to the
same network as the configuration device, or connected
directly to a configuration device via either WiFi or
Ethernet. The configuration device can be a smart phone,
tablet or computer.
Before making input, output or GPIO
connections to an AMP-4750 DSP amplifier it is
important that it is configured correctly, and if
necessary, has the presets required for the
loudspeakers that are to be used assigned to the
appropriate channels.
The AMP-4750 DSP is by default configured without any
DALI loudspeaker presets assigned to output channels,
however a library of DALI loudspeaker presets is stored
locally within the amplifier for assignment to output
channels. Assigning functional presets requires that the
AMP-4750 DSP amplifier is connected to mains power,
switched on, and connected to either a TCP/IP network
or directly to a configuration device for access to the
DALI CI AMP CONFIGURATOR interface.
NOTE
If access to the AMP CONFIGURATOR is not
required, jump to Section6 of this manual for guidance
on audio signal and loudspeaker or subwoofer
connections. Establishing network access to the AMP
CONFIGURATOR is however recommended in all cases.
5.2.1 Wired (Ethernet)
Connection
To connect an AMP-4750 DSP amplifier to a TCP/IP
network or directly to a configuration device using a
wired connection (Ethernet) follow the steps below.
1. Use an Ethernet cable to connect the AMP-4750 DSP
amplifier rear panel [Network Control] socket to a
free socket on a network router or switch, or directly
to an Ethernet equipped laptop or desktop computer.
2. With the AMP-4750 DSP amplifier connected to mains
power and switched on, the front panel [Network]
indicator will illuminate green to indicate that the
amplifier has network connectivi.
3. The AMP-4750 DSP amplifier default LAN IP address
is 192.168.64.100. Configure the laptop or desktop
computer for a fixed IP address in the same IP range;
eg. 192.168.64.10, with Subnet mask of 255.255.255.0
(or prefix 24) and set the Gateway to 192.168.64.1.
4. Open a smart phone, tablet or computer web browser
and enter the IP address: hp://192.168.64.100. The
DALI PHANTOM CI AMP CONFIGURATOR interface
will open to enable amplifier configuration as required.
NOTE:
AMP-4750 DSP amplifiers can be configured to use
DHCP for network connection if required. However, if
a AMP-4750 DSP amplifier using DHCP is switched o
and on, it is possible that the TCP/IP network router will
assign it a dierent IP address, leaving its configuration
page inaccessible via the previous IP address. If this
occurs, a network scanning app can be used to identi
the new IP address. DHCP and Fixed IP address option
seings can be found in the AMP CONFIGURATOR
[Seings] menu described in Section8 of this manual.
5.2.2 Wireless (WiFi) Connection
To connect an AMP-4750 DSP amplifier to a TCP/IP
network or directly to a configuration device using a
wireless connection (WiFi) follow the steps below.
1. With the AMP-4750 DSP amplifier connected to mains
power and switched on, the front panel WiFi indicator
will illuminate green to indicate the WiFi is available.
2. Use a mobile, laptop or desktop device to search
for available WiFi networks. Connect to “[AMP-4750
DSP] (product serial number)” using the password
“[password]”. The amplifier serial number can be found
on its rear panel.
3. Open a smart phone, tablet or computer web browser
and enter the IP address: 192.168.4.1. The DALI
PHANTOM CI AMP CONFIGURATOR interface will
open to enable amplifier configuration as required.
4. If it is required to connect the amplifier to
an alternative WiFi network, select the AMP
CONFIGURATOR [Seings] tab followed by [WiFi
> WiFi Mode > Client] to configure the amplifier to
connect to the required WiFi network. The WiFi
network name and password will be required.
It is strongly recommended that the AMP-4750 DSP
amplifier Access Point WiFi password is changed
following initial wireless connection.
Before you begin:
We recommend starting with Wi-Fi Hotspot setup,
before configuring a Wi-Fi or LAN connection.
Wi-Fi Hotspot Mode Setup:
The default Wi-Fi IP address is: 192.168.4.1
Ethernet/LAN Setup:
The default (fixed/static) LAN IP address is
192.168.64.100.
