18 | Electrical installation
Installer and user reference guide
68
FXNA-A
VRV system air conditioner
4P785124-1 – 2024.09
Power supply of the product
MCA
(a)
FXNA20~32: 0.9A
FXNA40~63: 1.1A
(a)
MCA=Minimum circuit ampacity. Stated values are maximum values (see electrical data of
indoor unit for exact values).
Wiring / circuit breaker (field supplied)
Power supply cable MUST comply with national wiring regulation.
3-core cable
Wire size based on the current, but not less than
1.5mm
2
Transmission wiring Only use harmonised wire providing double
insulation and suitable for applicable voltage
2-core cable
Minimum size 0.75mm
2
User interface cable Only use harmonised wire providing double
insulation and suitable for applicable voltage
2-core cable
Minimum size 0.75mm
2
Maximum length 500m
Recommended circuit breaker 6A
Residual current device MUST comply with national wiring regulation
18.2 To connect the electrical wiring to the indoor unit
NOTICE
▪ Follow the wiring diagram (delivered with the unit, located at the inside of the
service cover).
▪ For instructions on how to connect the optional equipment, see the installation
manual delivered with the optional equipment.
▪ Make sure the electrical wiring does NOT obstruct proper reattachment of the
service cover.
It is important to keep the power supply and the interconnection wiring separated
from each other. In order to avoid any electrical interference, the distance
between both wirings should ALWAYS be at least 50mm.
NOTICE
Be sure to keep the power line and interconnection line apart from each other.
Interconnection wiring and power supply wiring may cross, but may NOT run parallel.
1 Remove the service cover.
