D-EIMHP01405-21_11EN 31/52
5 ELECTRICAL INSTALLATION
5.1 General specifications
Refer to the specific wiring diagram for the unit you have bought. Should the wiring diagram not be on the unit, or should
it have been lost, please contact your manufacturer representative, who will send you a copy.
In case of discrepancies between wiring diagram and electrical panel/cables, please contact the manufacturer
representative.
All electrical connections to the unit must be carried out in compliance with laws and regulations in
force.
All installation, management and maintenance activities must be carried out by qualified personnel.
There is a risk of electric shock and burning.
Electrical equipment is capable of operating correctly in the intended ambient air temperature. For very hot/cold
environments (refer to “Operation limits”), additional measures are recommended (contact the manufacturer
representative).
The electrical equipment is capable of operating correctly when the relative humidity does not exceed 50% at a
maximum temperature of +40 °C. Higher relative humidities are permitted at lower temperatures (for example 90% at 20
°C).
The product meets the technical requirements of IEC 61000-3-11 and IEC 61000-3-12.
5.2 Electric connections
Provide an electrical circuit to connect the unit. It must be connected to the copper cables with an adequate section
relative to the absorption values and according to the current electrical standards.
Daikin Applied Europe S.p.A. declines all responsibility for an inadequate electrical connection.
The connections to the terminals must be made with copper terminals and cables, otherwise
overheating or corrosion may occur at the connection points with the risk of damaging the unit. The
electrical connection must be carried out by qualified personnel, in compliance with the laws in force.
There is a risk of electric shock.
The power supply to the unit must be set up in such a way that it can be switched on or off independently from that of
other system components and other equipment in general, by means of a general switch.
The electrical connection of the panel must be carried out maintaining the correct sequence of the phases. All units
require 4 conductor cables (3 phases + neutral) plus a ground conductor. Refer to the specific wiring diagram for the unit
you have bought. In case of discrepancy between the wiring diagram and electrical panel/cables, please contact the
manufacturer representative.
Do not apply torque, tension or weight to the main switch terminals. Power line cables must be
supported by appropriate systems.
To avoid interference, all control wires must be connected separately from the power cables. To do this, use several
electrical passage ducts.
Install a earth leakage breaker.
To avoid it from malfunctioning due to harmonics, use a a earth leakage breaker that is compatible with harmonics.
Before any electrical connection work to the compressor motor and / or the fans, make sure that the
system is switched off and the main switch of the unit is open. Failure to observe this rule could result
in serious personal injury.
5.3 Cable requirements
The cables connected to the circuit breaker must respect the insulation distance in the air and the surface isolation
distance between the active conductors and the earth, according to IEC 61439-1 table 1 and 2, and to the local national
laws.
The cables connected to the main switch must be tightened using a pair of keys and respecting the unified clamping
values, relative to the quality of the screws of the washers and nuts used.
