Main Switch
Model type
Value
Model Type
Value
63 A
Wohner 33825
Md min.: 2.0 Nm
Md max.: 2.0 Nm
Lovato GA063AT4V429
min Nm 5
max Nm 6
80 A
Wohner 33873
Md min.: 3.5 Nm
Md max.: 3.5 Nm
Lovato GA080AT4V429
min Nm 5
max Nm 6
100 A
Wohner 33877
Md min.: 3.5 Nm
Md max.: 3.5 Nm
Lovato GA100AT4V429
min Nm 5
max Nm 6
125 A
Wohner 33028
Md min.: 6.0 Nm
Md max.: 6.0 Nm
Lovato GA125AT4V429
min Nm 5
max Nm 6
Table 7 – Main Switch unified clamping values
Connect the earth conductor (yellow / green) to the PE ground terminal.
The equipotential protection conductor (earth conductor) must have a section according to table 1 of EN 602041 Point
5.2, shown below.
In any case, the equipotential protection conductor (earth conductor) must have a cross section of at least 10 mm2, in
accordance with point 8.2.8 of the same standard.
Section of the copper phase conductors
feeding the equipment
S [mm2]
Minimum cross section of the
external copper protection
conductor
Sp [mm2]
S ≤ 16
16 < S ≤ 35
S > 35
S
16
S/2
Table 8 - Table 1 of EN602041 Point 5.2
5.3.1 Maximum cable dimension
Maximum cable dimension that can be physically connected to mainswitch of the unit.
Modell
Max cable size (mm^2]
Model (A]
STD-Configuration
Max cable size (mm^2]
Model (A]
High ambient temperature
kit op. 192
EWAT/EWYT016CZ(N/P/H)-A1
16
63
16
63
EWAT/EWYT021CZ(N/P/H)-A1
16
63
16
63
EWAT/EWYT025CZ(N/P/H)-A1
16
63
16
63
EWAT/EWYT032CZ(N/P/H)-A1
16
63
50
100
EWAT/EWYT040CZ(N/P/H)-A1
16
63
50
100
EWAT/EWYT040CZ(N/P/H)-A2
50
80
50
80
EWAT/EWYT050CZ(N/P/H)-A2
50
80
50
80
EWAT/EWYT064CZ(N/P/H)-A2
50
100
70
125
EWAT/EWYT090CZ(N/P/H)-A2
70
125
70
125
