9 | Appendix
Application Guide
35
EKRACP* + EKRCTR* + EKRMIB* + EKRRVA* + EKRSEN* + EKRSIB* +
EKRUFH*
Daikin Home Controls
4P701747-1A – 2023.10
If you do decide to add a DHC Access Point to your ecosystem at a later point in
time, you will have to reset all accessories to factory settings. See "7.1Resetting to
factory settings"[426].
9.2.1 Single temperature water zone heating only unit with underfloor heating
a
b
d
e
f f
d
c
a Daikin Altherma (ext RT)
b DHC Basic IO Box
c DHC Floor Heating Controller
d DHC Room Thermostat — 2
e Collector
f Underfloor heating
To set up the configuration, you need to:
1 Connect the DHC Floor Heating Controller to the DHC Room Thermostat — 2,
2 Connect the DHC Floor Heating Controller to the DHC Basic IO Box, and
3 Configure the DHC Room Thermostat — 2.
To connect the DHC Floor Heating Controller to a DHC Room Thermostat — 2
INFORMATION
ALWAYS keep a minimum distance of 50cm between the accessories.
INFORMATION
You can cancel the connecting procedure by briefly pressing the system button again.
This will be indicated by the accessory LED lighting up red.
INFORMATION
If no connecting operations are carried out, connection mode is exited automatically
after 3 minutes.
If you want to connect the DHC Floor Heating Controller to a DHC Room
Thermostat — 2, the connection mode of both accessories has to be activated first.
To do this, proceed as follows:
1 Press the select button briefly to select a channel. Press once for channel 1,
twice for channel 2, etc.
