Je bekijkt pagina 38 van 52
38
Technician – Parameters
P25 Speed level (Manual)
Function only if P24 = 1 is selected (Op. mode speed cntrl = Manual).
P25 = 30 – 100%: Specifies the speed for pump A1.
P26 Min. Speed level (Auto)
Function only if P24 = 0 is selected (Op. mode speed cntrl =
Automatic).
P26 = 30 – 100%: To define the minimum speed in % at which pump
A1 is to run. Select the value such that the pump runs reliably at this
speed (P26 < P27).
P27 Max. Speed level (Auto)
Function only if P24 = 0 is selected (Op. mode speed cntrl =
Automatic).
P27 = 30 – 100%: To define the maximum speed in % at which pump
A1 is to run. Select the value such that the pump runs reliably at this
speed (P27 > P26).
P28 Temperature difference for 100% control
Function only if P24 = 0 is selected (Op. mode speed cntrl =
Automatic).
P28 = 5 – 50 K: The pump is started at full speed [100%] for the
temperature difference between collector 1 and the active storage
tank that is set here. The pump is slowed down if the temperature
difference is lower.
ON/OFF switching differences, hysteresis
P30 Switch-on threshold 1
P30 = 1 – 30 K: The feeding function for storage tank 1 via pump
A1 is enabled when the temperature difference between sensor F1
(collector/solid fuel) and sensor F4 (storage tank bottom) exceeds
the switch-on threshold.
P31 Switch-off threshold 1
P31 = 1 – 30 K: The feeding function for storage tank 1 is barred
when the temperature difference between sensor F1 (collector/solid
fuel) and sensor F4 (storage tank bottom) drops below the switch-
off threshold.
P32 Switch-on threshold 2,
P33 Switch-off threshold 2
P32, P33 = 1 – 30 K.
Systems 1, 7, 9, 13: No function.
Systems 2, 5: The feeding function for storage tank 2 via pump
A1 is enabled when the temperature difference between sensor
F1 (solid fuel/collector) and sensor F2 (storage tank 2) exceeds the
switch-on threshold.
The feeding function for storage tank 2 is deactivated again when
the difference drops below the set switch-off threshold.
The valve A2 is switched in the direction of storage tank 2 when the
feeding function for storage tank 2 is enabled and storage tank 1
cannot be fed.
Systems 3, 4: The feeding function via pump A2 is enabled when the
temperature difference between sensor F2 (solid fuel/ collector 2) and
sensor F4 (storage tank bottom) exceeds the switch-on threshold.
System 6: The feeding function for storage tank 2 via pump A2 is
enabled when the temperature difference between sensor F1 (collec-
tor) and sensor F2 (storage tank 2) exceeds the switch-on threshold.
The feeding function for storage tank 2 is deactivated again when
the difference drops below the set switch-off threshold.
System 8: see page 28 (Reheating)
System 10: The refeeding function via pump A2 is enabled when
the temperature at sensor F3 (tank top 1) exceeds the temperature
at sensor F2 (tank bottom 2) by the switch-on threshold (P32).
