39
Technician – Parameters
The refeeding function via pump A2 is deactivated again when the
temperature at sensor F3 (tank top 1) drops below the temperature
at sensor F2 (tank bottom 2) by the switch-off threshold (P33).
System 11: Valve A2 switches on when the temperature at sensor
F1 (collector) exceeds the temperature at sensor F3 (storage tank
top) by the switch-on threshold (P32).
Valve A2 switches off when the temperature at sensor F1 (collector)
drops below the temperature at sensor F3 (storage tank top) by the
switch-off threshold.
System 12: Valve A3 switches on when the temperature at sensor
F1 (collector) exceeds the temperature at sensor F3 (storage tank
top) by the switch-on threshold.
Valve A3 switches off when the temperature at sensor F1 (collector)
drops below the temperature at sensor F3 (storage tank top) by the
switch-off threshold (feeding into the middle or upper storage tank
section).
Valve A2 switches on when the temperature at sensor F1 (collector)
exceeds the temperature at sensor F5 (middle storage tank) by the
switch-on threshold (feeding into the middle or upper storage tank
section).
Valve A2 switches off when the temperature at sensor F1 (collector)
drops below the temperature at sensor F5 (middle storage tank) by
the switch-off threshold (feeding into the lower storage tank section).
P34 Hysteresis reheating
P34 = 1 – 30 K: Reheating is activated when the set temperature
drops below the hysteresis set here. Reheating is deactivated again
when the set temperature set with P47 is exceeded.
Special functions
P40 Collector enable temperature,
P41 Collector disable temperature
P40, P41 = -20 – +95°C:
Systems 2, 9: No function
System 1, 3, 4, 5, 6, 7, 8, 10, 11, 12: The collector pump is enabled
when the associated collector temperature exceeds the enable tem-
perature. It is disabled when the collector temperature drops below
the disable temperature. This function prevents
the pump starting without relevant heat production.
System 13: Collector pumps A1 and A2 are enabled when the
associated collector temperature exceeds the enable temperature.
The collector pumps remain active for the filling time set with P87.
P42 Maximum collector temperature
P42 = 80 – 180°C:
Systems 2, 9: No function
Systems 1, 3, 4, 5, 6, 7, 8, 10, 11, 12, 13: The collector pumps are
deactivated when the associated collector temperature exceeds the
safety limit set here (system protection).
The pumps are reactivated when the temperature drops below the
maximum collector temperature – 10K.
P43 Enable temperature 2nd heat gen. (solid fuel boiler)
P43 = 0 – 90°C:
Systems 1, 4, 5, 6, 7, 8, 10, 11, 12, 13: No function.
Systems 2, 3, 9: The corresponding pump is enabled when the
temperature of the 2nd heat source (systems 2 and 9 = F1, sys-
tem3 = F2) exceeds the limit set here by 5K. It is disabled when the
temperature of the heat source drops below the enable temperature.
