Technician – Parameters
P
No.
Parameter Setting range Factory setting
Own
val-
ues
76 Vol. flow - collector2
OFF;
0.1l/min to 100 l/min
OFF
78 Mixing ratio 0% to 70% 40%
79 Glycol type
Propylene glycol;
Ethylene glycol
Propylene glycol
Drain back
84 Max tank output 50°C to 75°C 68°C
85 Max tank input active 60°C to 110°C 95°C
86
Max tank output
active
60°C to 110°C 75°C
87 Filling time 1 min to 10 min 3 min
Software
99 Software no. Display only
Pump controller PWM-/0…10V
101 Speed control variant PWM; 0…10 V PWM
102 PWM base frequency
180 Hz; 1 kHz;
2 kHz
180 Hz
103 PWM ratio ON 0% to 100% 15%
104 PWM ratio OFF 0% to 100% 0%
105 PWM ratio Pmin 0% to 100% 15%
106 PWM ratio Pmax 0% to 100% 100%
107 PWM ratio Povrsped OFF; 0% to 100% Off
108 Voltage 0% 0 to 10 V 0 V
109 Voltage 100% 0 to 10 V 10 V
110 Voltage OFF 0 to 10 V 0 V
Explanation of the parameters
P21 Code No.
Here you can specify your own code number. Remember this code
well! This code number is required to change parameters 22, 24 – 110
and to reset the controller.
ڀ Factory setting = 0000.
ڀ If the code number is not known and to reset the code number,
hold the OK button pressed and connect the power supply to
the controller.
Changing the code number, see pages 32 (Technician – Settings)
and 33 (Change Code no.).
P22 Select system
On selecting the system, the function of the device is redefined. Set
the number of the system according to the connection descriptions
for system 1 to system 13, see from page 17 (System schemes).
ڀ After changing the Select system parameter, all settings except
the selected language are reset to the factory settings (code
number is reset to 0000).
Speed control A1/A2
P23 Speed level value
Display of the actual value for the speed of pump A1 and pump A2
(if installed) in %.
ڀ Display without input of the code number.
P24 Op. mode speed cntrl
P24 = 0: Automatic, the differential controller determines the speed
for A1/A2.
P24 = 1: Manual, the speed set under P25 applies to A1/A2.
