4 | Preparation
Installer reference guide
18
BRP069A61+BRP069A62
Daikin Altherma LAN adapter
4P464229-1E – 2023.11
4.2.4 Solar inverter/energy management system
INFORMATION
Before installation, confirm that the solar inverter/energy management system is
equipped with the digital outputs required to connect it to the LAN adapter. For
more information, see "7Smart Grid application"[437].
Connector X1A is for the connection of the LAN adapter to the digital outputs of a
solar inverter/energy management system, and allows for the integration of the
heat pump system in a Smart Grid application.
X1A/N+L supply a 230 V AC detection voltage to the input contact of X1A. The
230VAC detection voltage enables the detection of the state (open or close) of
the digital inputs and does NOT supply power to the rest of the LAN adapter PCB.
Make sure X1A/N+L are protected by a fast acting circuit breaker (rated current
100mA~6A, typeB).
The rest of the wiring to X1A differs depending on the digital outputs available on
the solar inverter/energy management system and/or on the Smart Grid operation
modes that you want the system to run in. For more information, see "7Smart Grid
application"[437].
