MENU/IN 1 Button: When not in source selection mode, press to
enter the OSD menu, or to back out from menu items. When source
selection is active, pressing this button will select input 1 for the
currently selected output/window.
Note: Pressing “MENU” and “+” together will reset the output resolution
to XGA (1024x768@60Hz). Pressing “MENU” and “-” together will reset the
output resolution to 1080p@60Hz.
7
Minus (-)/IN 2 Button: When not in source selection mode, press
to move down or adjust selections within OSD menus. When source
selection is active, pressing this button will select input 2 for the
currently selected output/window.
8
Plus (+)/IN 3 Button: When not in source selection mode, press
to move up or adjust selections within OSD menus. When source
selection is active, pressing this button will select input 3 for the
currently selected output/window.
9
ENTER/IN 4 Button: When not in source selection mode, press to
conrm a selection within the OSD. When source selection is active,
pressing this button will select input 4 for the currently selected
output/window.
10
FUNCTION 1~2 Buttons and LEDs: The functionality of these buttons
depends on the current SDM Module card installed (for example,
starting and stopping recording, or streaming).
11
MIC 1~2 Volume Knobs & Ports: Connect each port to the analogue
mono output of a microphone. Rotate each mic’s knob to increase or
decrease the audio gain for the associated microphone.
Note: Microphone input gain can only be controlled via these physical
knobs and cannot be modified through the WebGUI or Telnet.
