7
7
IR WINDOW: Accepts IR signals from any standard remote control and
sends the signal to the IR Out on the associated Receiver.
Note: When the Transmitter is in multicast mode the IR signal is sent to all
associated Receivers.
8
LOOPBACK/LINK: This button controls multiple functions:
a
Loopback: Press this button momentarily to toggle the VGA Loopback
function on and o, allowing you to locally monitor non-HDCP HDMI
sources (1080p or below) for troubleshooting purposes.
b
Video Link: Press and hold the button for 3 seconds to enable or
disable the Video Link. When the link is disabled and the Receiver
is connected to a display it will show the system’s current IP and
rmware information.
c
Reset to Factory Defaults: Press and hold this button when powering
the unit on until both the POWER and LINK lights are blinking. Once
both lights are blinking you can reboot the unit and all settings will
be returned to the factory defaults (Including resetting the IP mode to
auto, broadcast channel to 0, and the streaming mode to multicast). A
new IP address will be assigned automatically within the 169.254.xxx.
xxx address range.
9
MODE/Anti-DITHER: This button controls multiple functions:
a
Video Mode: Press this button momentarily to toggle the video data
streaming method between “Graphic” and “Video” modes. “Graphic”
mode is optimised for high-detail static displays and “Video” mode is
optimised for full motion video.
b
Anti-Dither: Press and hold this button for 3 seconds to enable
and switch between the three “Anti-Dither” modes (1-bit, 2-bit and
o). Certain graphics cards use dithering to emulate a larger colour
palette, but dithering causes diculty for maintaining low-bandwidth
during real-time video compression, so these Anti-Dithering modes
are designed to remove the dithering prior to compression and
transmission of the signal. If the source is not using dithering, please
leave this feature disabled as it may cause a blocking eect with non-
dithered content.
Note: This feature is set to “o” by default.
10
ISP: For factory use only.
11
RESET: Press this recessed button to reboot the unit (Settings will not
be reset).
