6.3.2 Video Wall Unit Search
By clicking on the “Search” button at the top-right corner of the window,
all Video Wall Rotation Processors that are located on the local network
or are directly connected via RS-232 can automatically discovered. Each
detected unit can then be added to the current video wall layout and
assigned a unique ID number.
1) Search Button: Click on the “Search” button to open the Unit
Selection Window. All detected units on the local network as well as all
available local serial ports will be listed in the “All Units” section. After
all units have been selected and arranged, click on the “OK” button to
add them to the layout.
Note: Units connected via RS-232 can’t be directly detected, so all
available serial ports will be listed, even if they do not currently have a
connected unit.
■
All Units List: All detected units on the local network as well as
all available local serial ports are listed here. All detected units
are identified by their IP address. If additional units are added to
the network after the window is opened, click “Refresh” to detect
them. Selecting a Unit (or serial port) and then clicking the right
arrow button ( ) will place them in the Selected Units window in
the order they are added. The Ethernet details of each detected
unit may also be changed by clicking on the associated details
icon ( ).
■
Selected Units: All selected units will appear here with an ID
