4 — CANopen COMMUNICATIONS
Curtis 1355 CANopen Soft Starter Module Manual – September 2020
Return to TOC
pg. 24
PARAMETER PROFILE OBJECTS
e parameter prole objects are shown in Table 5.
Table 5 Parameter Profile Object Dictionary
NAME ACCESS INDEX SUB-INDEX
RANGE
RAW MAPPING Description
PDO1 RX Parameters RO 0x1400 0x00 1 No Number of PDO1 RX parameters.
0x01 n/a The rst parameters of PDO1 RX.
PDO2 RX Parameters RO 0x1401 0x00 1 No Number of PDO2 RX parameters.
0x01 n/a The rst parameters of PDO2 RX.
PDO1 RX Mapping RW 0x1600 0x00 n/a No Number of mapped application objects
in PDO1 RX.
PDO1 RX Mapping 1 0x01 PDO1 RX mapping for the 1st application
object to be mapped.
PDO1 RX Mapping 2 0x02 PDO1 RX mapping for the 2nd
application object to be mapped.
. . . . . . PDO1 RX mapping for 3rd–7th objects.
PDO1 RX Mapping 8 0x08 PDO1 RX mapping for the 8th application
object to be mapped.
PDO2 RX Mapping RW 0x1601 0x00 n/a No Number of mapped application objects
in PDO2 RX.
PDO2 RX Mapping 1 0x01 PDO2 RX mapping for the 1st application
object to be mapped.
PDO2 RX Mapping 2 0x02 PDO2 RX mapping for the 2nd
application object to be mapped.
. . . . . . PDO2 RX mapping for 3rd–7th objects.
PDO2 RX Mapping 8 0x08 PDO2 RX mapping for the 8th application
object to be mapped.
PDO1 TX Parameters RO 0x1800 0x00 1 No Number of PDO1 TX parameters.
0x01 n/a The rst parameters of PDO1 TX.
PDO2 TX Parameters RO 0x1801 0x00 1 No Number of PDO2 TX parameters.
0x01 n/a The rst parameters of PDO2 TX.
PDO1 TX Mapping RW 0x1A00 0x00 n/a No Number of mapped application objects
in PDO1 TX.
PDO1 TX Mapping 1 0x01 PDO1 TX mapping for the 1st application
object to be mapped.
PDO1 TX Mapping 2 0x02 PDO1 TX mapping for the 2nd
application object to be mapped.
. . . . . . PDO1 TX mapping for 3rd–7th objects.
PDO1 TX Mapping 8 0x08 PDO1 TX mapping for the 8th application
object to be mapped.
