4 — CANopen COMMUNICATIONS
pg. 25
Return to TOC Curtis 1355 CANopen Soft Starter Module Manual – September 2020
NAME ACCESS INDEX SUB-INDEX
RANGE
RAW MAPPING Description
PDO2 TX Mapping RW 0x1A01 0x00 n/a No Number of mapped application objects
in PDO2 TX.
PDO2 TX Mapping 1 0x01 PDO2 TX mapping for the 1st application
object to be mapped.
PDO2 TX Mapping 2 0x02 PDO2 TX mapping for the 2nd
application object to be mapped.
. . . . . . PDO2 TX mapping for 3rd–7th objects.
PDO2 TX Mapping 8 0x08 PDO2 TX mapping for the 8th application
object to be mapped.
Nominal Voltage RW 0x3048 0x00 1536 – 2304,
2304 – 3072
No 24–36V for 1355-4X01,
36–48V for 1355-5X01.
M1 Current Limit RW 0x3101 0x00 100 – 1000,
or 100 – 700
No Denes the maximum current of M1:
10 –100A for 1355-4X01 and
10 –70A for 1355-5X01.
M2 Current Limit RW 0x3102 0x00 100 – 1000,
or 100 – 700
No Denes the maximum current of M2:
ranges are as shown for M1.
M3 Current Limit RW 0x3103 0x00 100 – 1000,
or 100 – 700
No Denes the maximum current of M3:
ranges are as shown for M1.
M4 Current Limit RW 0x3104 0x00 100 – 1000,
or 100 – 700
No Denes the maximum current of M4:
ranges are as shown for M1.
M5 Current Limit RW 0x3105 0x00 100 – 1000,
or 100 – 700
No Denes the maximum current of M5:
ranges are as shown for M1.
Motor Control RW 0x3106 0x00 0 – 255 Yes bit0 controls M1 1=Run 0=Stop.
bit1 controls M2 1=Run 0=Stop.
bit2 controls M3 1=Run 0=Stop.
bit3 controls M4 1=Run 0=Stop.
bit4 controls M5 1=Run 0=Stop.
bit5 controls H Bridge direction:
1=Fwd 0=Rev. Note: in H-Bridge
mode, the 1355 uses the parameters
of M1; M2’s parameters are ignored.
Motor Mode RW 0x3107 0x00 0 – 255 Yes bit0 M1 PWM mode 1=Active 0=Inactive.
bit1 M2 PWM mode 1=Active 0=Inactive.
bit2 M3 PWM mode 1=Active 0=Inactive.
bit3 M4 PWM mode 1=Active 0=Inactive.
bit4 M5 PWM mode 1=Active 0=Inactive.
M1 Overload Time RW 0x3108 0x00 1000 –20000 No Denes the max overload time:
1000 – 20000 ms.
The output is shut down once the timer
expires.
M2 Overload Time RW 0x3109 0x00 1000 –20000 No
M3 Overload Time RW 0x310A 0x00 1000 –20000 No
M4 Overload Time RW 0x310B 0x00 1000 –20000 No
M5 Overload Time RW 0x310C 0x00 1000 –20000 No
M1 Accel RW 0x310D 0x00 1– 20 No 0.1– 2.0 s
M2 Accel RW 0x310E 0x00 1– 20 No 0.1– 2.0 s
M3 Accel RW 0x310F 0x00 1– 20 No 0.1– 2.0 s
M4 Accel RW 0x3113 0x00 1– 20 No 0.1– 2.0 s
Table 5 Parameter Profile Object Dictionary, cont'd
