3 — PROGRAMMER MENUS
Curtis 1355 CANopen Soft Starter Module Manual – September 2020
Return to TOC
pg. 16
CAN INTERFACE MENU
PARAMETER ALLOWABLE RANGE DESCRIPTION
Node ID 1 – 127 Sets the Node ID of the 1355 CANopen ancillary system.
Must cycle KSI or send an NMT RESET 1355 or an NMT RESET CAN for the
new ID to take full effect.
Baud Rate 0 – 2 Sets the CAN bus baud rate.
0 = 125 kbps.
1 = 250 kbps.
2 = 500 kbps.
Must cycle KSI or send an NMT RESET 1355 or an NMT RESET CAN for the
new rate to take effect.
Heartbeat Rate 16 – 1000 ms Sets the rate at which heartbeat messages are sent from the 1355.
PDO Timeout 0 – 1000 ms Sets the PDO timeout period.
After the 1355 has sent a PDO TX, it will declare a PDO Timeout Fault if
the manager controller has not sent a reply PDO-RX message within the
programmed time. Either PDO1 RX or PDO2 RX will reset the timer.
Setting this PDO Timeout = 0 will disable this fault check.
MISC MENU (1355-X101 only)
PARAMETER ALLOWABLE RANGE DESCRIPTION
Digital Input 1 Normally Closed On / Off On = Normally closed.
Off = Normally open.
Digital Input 2 Normally Closed On / Off On = Normally closed.
Off = Normally open.
Digital Input 3 Normally Closed On / Off On = Normally closed.
Off = Normally open.
Digital Input 4 Normally Closed On / Off On = Normally closed.
Off = Normally open.
Digital Input 5 Normally Closed On / Off On = Normally closed.
Off = Normally open.
Digital Input 6 Normally Closed On / Off On = Normally closed.
Off = Normally open.
a
1355-X001 only
b
1355-X101 only
