3 — PROGRAMMER MENUS
pg. 17
Return to TOC Curtis 1355 CANopen Soft Starter Module Manual – September 2020
MONITOR MENUS
rough its monitor menus, the Curtis programmer provides access to real-time data during vehicle
operation. This information is helpful during diagnostics and troubleshooting, and also while
adjusting programmable parameters.
e monitored variables are arranged in menus, as shown in Table 3.
Table 3 Monitor Menus: 1311/1313 /1314 Programmer
CURRENT..................................... p. 18
— M1 Current
— M2 Current
— M3 Current
— M4 Current
— M5 Current
— Actuator 1 Current
a
— Actuator 2 Current
a
— Actuator 3 Current
a
VOLTAGE.................................... p. 18
— KSI Voltage
— Battery Voltage
DUTY CYCLE................................. p. 18
— M1 Duty Cycle
— M2 Duty Cycle
— M3 Duty Cycle
— M4 Duty Cycle
— M5 Duty Cycle
— Actuator 1 Duty Cycle
a
— Actuator 2 Duty Cycle
a
— Actuator 3 Duty Cycle
a
CONTROLLER............................... p. 19
— Internal Temperature
— Contactor State
— Interlock
b
— Digital Input 1
b
— Digital Input 2
b
— Digital Input 3
b
— Digital Input 4
b
— Digital Input 5
b
— Digital Input 6
b
— M1 Hourmeter
— M2 Hourmeter
— M3 Hourmeter
— M4 Hourmeter
— M5 Hourmeter
— Actuator 1 Hourmeter
a
— Actuator 2 Hourmeter
a
— Actuator 2 Hourmeter
a
— CAN NMT State
a
1355-X001 only
b
1355-X101 only
