3 — PROGRAMMABLE PARAMETERS
pg. 65
Return to TOC Curtis Model 1226BL – July 2024
DRIVERS SETTING MENU, cont’d
PARAMETER
CAN INDEX
VALUES
DEFAULT
RAW VALUES
DATA SIZE DESCRIPTION
Valve Driver Checks Enable
0x341D01
Off/On
On
0–1
8-bit
Species whether the controller checks the driver for the
open condition:
On = If the open condition occurs, the controller opens the
driver and generates the Valve Driver Fault.
Off = The controller does not check for the open condition.
CAUTION: Specifying Off may make the system non-compliant
with EN 1175:2020 and may cause a higher probability of
dangerous failure. Regulatory compliance of the complete
vehicle system, including this setting, is the responsibility of the
vehicle OEM.
Pump Contactor Driver
Compensation
0x341F01
Off/On
On
0–1
8-bit
Species the driver PWM mode.
On = Voltage Compensated PWM mode
Off = Direct PWM mode
For descriptions of the PWM modes, see Driver Outputs.
Valve Driver Compensation
0x342001
Off/On
On
0–1
8-bit
Species the driver PWM mode.
On = Voltage Compensated PWM mode
Off = Direct PWM mode
Pump SRO Enable
0x335D01
Off/On
On
0–1
16-bit
Species whether the controller generates a Pump SRO fault if
either of the following conditions occurs:
• The lift switch is closed when the keyswitch is turned on
(fault type 1).
• The Pump On Interlock parameter species On and the
lift switch is closed before the interlock is turned on (fault
type 3).
CAUTION: Specifying Off may make the system non-compliant
with EN 1175:2020 and may cause a higher probability of
dangerous failure. Regulatory compliance of the complete
vehicle system, including this setting, is the responsibility of the
vehicle OEM.
Valve SRO Enable
0x335F01
Off/On
On
0–1
16-bit
Species whether the controller generates a Valve SRO fault if
either of the following conditions occurs:
• The valve switch is closed when the keyswitch is turned
on (fault type 1).
• The Valve On Interlock parameter species On and the
valve switch is closed before the interlock is turned on
(fault type 3).
CAUTION: Specifying Off may make the system non-compliant
with EN 1175:2020 and may cause a higher probability of
dangerous failure. Regulatory compliance of the complete
vehicle system, including this setting, is the responsibility of the
vehicle OEM.
Pump On Interlock
0x336101
Off/On
Off
0–1
16-bit
Species whether the lift function is available only when the
Interlock state is On.
Valve On Interlock
0x336201
Off/On
Off
0–1
16-bit
Species whether the lower function is available only when the
Interlock state is On.
Enable Lower In Creep Mode
0x532A00
Off/On
On
0–1 Species whether the lower function is available in creep mode.
To enable lowering in creep mode, Valve On Interlock must also
specify On.
Pump Driver Pull In Voltage
0x342201
0–100%
100%
0–32767
16-bit
Species the pump contactor's initial voltage when the
system is rst turned on, to ensure that the contactor is
engaged. After 1 second, the peak voltage drops to the Pump
Driver Holding Voltage.
