3 — PROGRAMMABLE PARAMETERS
Curtis Model 1226BL – July 2024 Return to TOC
pg. 66
DRIVERS SETTING MENU, cont’d
PARAMETER
CAN INDEX
VALUES
DEFAULT
RAW VALUES
DATA SIZE DESCRIPTION
Pump Driver Holding Voltage
0x342301
0–100%
80%
0–32767
16-bit
Species the reduced voltage the controller applies to the
pump contactor coil once the contactor has been engaged.
Set the holding voltage so that it is high enough to keep the
contactor engaged under all shock and vibration conditions that
the vehicle is expected to encounter.
Valve Driver Pull In Voltage
0x342401
0–100%
100%
0–32767
16-bit
Species the contactor’s initial voltage when the system is
rst turned on, to ensure that the valve contactor is engaged.
After 1 second, the peak voltage drops to the Valve Driver
Holding Voltage.
Valve Driver Holding Voltage
0x342501
0–100%
80%
0–32767
16-bit
Species the reduced voltage the controller applies to the valve
contactor coil once the contactor has been engaged.
Set the holding voltage so that it is high enough to keep the
contactor engaged under all shock and vibration conditions that
the vehicle is expected to encounter.
External Status LED Enable
0x342901
Off/On
Off
0–1
8-bit
Indicates whether pin J3-2 is used to drive an external status
LED or a valve contactor:
On = External status LED
Off = Valve contactor
If the value is On but the Type parameter of the Digital/Analog
Input 1 or the Digital/Analog Input 2 menu is 1 (Lower Valve
Input), a Parameter Mismatch fault will occur.
First-On Mode
0x516100
Off/On
Off
0–1
8-bit
Species whether the traction and lift can work together:
Off = The traction and lift can work together.
On = The traction and lift cannot work together.
Enable Lift Timeout
0x525000
Off/On
Off
0–1
8-bit
Species whether the Lift Timeout is enabled.
Lift Timeout
0x524F00
0–90s
0s
0–2880
16-bit
Species the lift timeout.
If Enable Lift Timeout species On, the controller will turn off
the lift function if the timeout expires.
