3 — PROGRAMMABLE PARAMETERS
Curtis Model 1226BL – July 2024 Return to TOC
pg. 38
MOTOR TEMPERATURE CONTROL MENU
e following table describes the parameters on the Motor Temperature Control menu. For more
information, see Motor Temperature Sensor.
MOTOR TEMPERATURE CONTROL MENU
PARAMETER
CAN INDEX
VALUES
DEFAULT
RAW VALUES
DATA SIZE DESCRIPTION
Sensor Enable
0x368601
Off/On
Off
0–1
16-bit
Species whether the motor temperature control function is
enabled.
When the temperature sensor is enabled, the controller applies
the motor temperature control features when the motor
temperature is between the Temperature Hot and Temperature
Max temperatures.
Sensor Type
0x368801
1–5
3
1–5
16-bit
Species the type of temperature sensor used by the vehicle.
The following values represent the controller’s predened
sensor types:
1 = KTY83–122
2 = 2 KTY83–122 sensors, in series
3 = KTY84–130 or KTY84–150
4 = 2 KTY84–130 or KTY84–150 sensors, in series
5 = PT1000
Note: The industry standard KTY temperature sensors are
silicon temperature sensors with a polarity band (cathode). The
polarity band must be connected to I/O Ground.
Sensor Temp Offset
0x368701
−20 – +20°C
0°C
−200 – +200
16-bit
Species a temperature by which the controller compensates
for known offsets in the vehicle system’s components. Use this
parameter to handle conditions such as the following:
• The sensor is placed in the motor at a location with a
known offset to the critical temperature.
• The sensor itself has a known offset.
Braking Thermal Cutback
Enable
0x368001
Off/On
Off
0–1
8-bit
Species whether the controller cuts back regen braking
current if the motor reaches the Temperature Hot threshold:
On = The controller cuts back current for all forms of regen
braking, including emergency reverse braking, interlock
braking, neutral braking, and speed limit braking.
Off = The controller does not cut back regen braking current.
Regardless of the parameter value, the controller cuts back the
drive current if the motor reaches the Temperature Hot threshold.
Note: If the vehicle has mechanical brakes, enabling this
cutback might reduce motor heating.
Temperature Hot
0x368301
0–250°C
145°C
0–2500
16-bit
Species the temperature at which the controller starts cutting
back current.
Temperature Max
0x368501
0–250°C
160°C
0–2500
16-bit
Species the temperature at which the controller cuts back
all current.
Motor Temp LOS Max Speed
0x368401
0–100%
50%
0–8192
16-bit
Species the maximum speed after a Motor Temp Sensor
fault occurs.
The value is a percentage of the active speed mode’s Max
Speed parameter.
When a Motor Temp Sensor fault occurs, the controller applies
a limited operating strategy (LOS) that reduces the maximum
speed by the specied percentage.
