3 — PROGRAMMABLE PARAMETERS
Curtis Model 1220E – August 2022 Return to TOC
pg. 32
RPDO2 MAPPING
NAME
ALLOWABLE
RANGE RAW DATA DESCRIPTION
Length
(0x160100, 8bits)
0 – 8
0 – 8
Denes the maximum supported sub-index.
Map 1
(0x160101, 32bits)
0 – 0xFFFFFFFF
0 – 0xFFFFFFFF
Default mapping to Sypglass data 1 for gauge 840.
Map 2
(0x160102, 32bits)
0 – 0xFFFFFFFF
0 – 0xFFFFFFFF
Default mapping to Sypglass data 2 for gauge 840.
Map 3
(0x160103, 32bits)
0 – 0xFFFFFFFF
0 – 0xFFFFFFFF
Default mapping to Sypglass data 3 for gauge 840.
Map 4
(0x160104, 32bits)
0 – 0xFFFFFFFF
0 – 0xFFFFFFFF
Default mapping to Sypglass data 4 for gauge 840.
Map 5
(0x160105, 32bits)
0 – 0xFFFFFFFF
0 – 0xFFFFFFFF
Default mapping to Sypglass data 5 for gauge 840.
Map 6
(0x160106, 32bits)
0 – 0xFFFFFFFF
0 – 0xFFFFFFFF
Default mapping to Sypglass data 6 for gauge 840.
Map 7
(0x160107, 32bits)
0 – 0xFFFFFFFF
0 – 0xFFFFFFFF
Default mapping to Sypglass data 7 for gauge 840.
Map 8
(0x160108, 32bits)
0 – 0xFFFFFFFF
0 – 0xFFFFFFFF
Default mapping to Sypglass data 8 for gauge 840.
TPDO2 MAPPING
NAME
ALLOWABLE
RANGE RAW DATA DESCRIPTION
Length
(0x1A0100, 8bits)
0 – 8
0 – 8
Denes the maximum supported sub-index.
Map 1
(0x1A0101, 32bits)
0 – 0xFFFFFFFF
0 – 0xFFFFFFFF
Default mapping to the inverted enable traction.
Map 2
(0x1A0102, 32bits)
0 – 0xFFFFFFFF
0 – 0xFFFFFFFF
Default mapping to the inverted traction cutback.
Map 3
(0x1A0103, 32bits)
0 – 0xFFFFFFFF
0 – 0xFFFFFFFF
Default mapping to the switches state.
Map 4
(0x1A0104, 32bits)
0 – 0xFFFFFFFF
0 – 0xFFFFFFFF
Default mapping to the switches state of supervisor.
Map 5
(0x1A0105, 32bits)
0 – 0xFFFFFFFF
0 – 0xFFFFFFFF
Default mapping to the command analog input 2.
Map 6
(0x1A0106, 32bits)
0 – 0xFFFFFFFF
0 – 0xFFFFFFFF
Default mapping to the auxiliary analog input of supervisor.
Map 7
(0x1A0107, 32bits)
0 – 0xFFFFFFFF
0 – 0xFFFFFFFF
No mapping.
Map 8
(0x1A0108, 32bits)
0 – 0xFFFFFFFF
0 – 0xFFFFFFFF
No mapping.
