ENGLISH

8

Pole Pruner Trimming/Pruning (Fig. A, K)



DANGER:

Keep hands and other body parts away

from the blade. Contact with the blade will result in

serious personalinjury.



WARNING: To guard against injury, observe the following:

• Read instruction manual before using. Save

instructionmanual.

• Check the shrub for foreign objects such as wires or

fences before eachuse.

• Keep one hand grip the main handle firmly with the

other hand on the foam gripper with the thumb

and fingers encircling them. Don'toverreach.

• Do not use under wetconditions.



CAUTION: Do not use blade to cut branches greater

than 1.25" (32mm). Use the pruner only for cutting

normal branches less than 1.25" (32mm) in diameter

around houses andbuildings.

IMPORTANT: Never operate a pole pruner that is damaged

or improperly adjusted or that is not completely and

securely assembled. Be sure that the cutting blade

8

stops

moving when the trigger switch is released. Never adjust the

cutting blade

8

when the motor is operating or the battery

isattached.



WARNINGS:

• Never stand directly under the limb you are cutting.

Always position yourself out of the path of fallingdebris.

• Always wear head, eye, foot and body protection.

Wearing body protection helps reduce the risk of injury

when operating thisunit.

• Always use two hands when operating the extended

reach pruner. Hold the extended reach pruner with both

hands to avoid loss of control.

• Never stand on a ladder or other unstable support

while using the pole pruner. Always avoid any position

which can cause you to loose your balance and cause

severeinjury.

• Keep other persons at least 50' (15m) from the work

area. Distractions can cause you to losecontrol.

• Electrocution Hazard. To prevent shock, do not operate

within 50' (15m) of overhead electrical lines. Always check

surrounding area for hidden electricallines.

• Do not hold pole pruner switch handle above

shoulderheight.

Working Position (Fig. I, J)

Maintain proper footing and balance and do not overreach.

Wear safety goggles, non-skid footwear and gloves when

pruning. Hold the tool firmly. Always hold the pruner, as

shown in Fig. I. Refer to Proper Hand Position for more

information. Never hold the tool by theblades.

1. Position the branch to be cut between the cutting

blade

8

and fixed blade

9

.

2. Push the lock off button

6

down and then squeeze the

trigger switch

5

.

3. The cutting blade

8

will make a cut cycle and cut the

branchoff.

4. Release the triggerswitch.

NOTE: If more branches need to be cut, at the same

time, the lock-off switch

6

can be held down and

actuate the trigger switch

5

as needed. Otherwise,

repeat steps 1-4.

Removing and Installing Blade (Fig. M)



DANGER: To reduce the risk of serious personal

injury, turn unit off, remove battery pack before

making any adjustments or removing/installing

attachments or accessories. An accidental start‑up

can causeserious personalinjury.



DANGER: RISK OF INJURY. WHEN REASSEMBLING

THE BLADE SYSTEM, ENSURE EACH PART IS

REINSTALLED CORRECTLY, AS DESCRIBED BELOW.

IMPROPER ASSEMBLY OF THE BLADE OR OTHER PARTS

OF THE BLADE SYSTEM CAN CAUSE SERIOUSINJURY.



WARNING: Use gloves and proper eye protection. Be

careful of the sharp edges on theblade.

Replacement blades are available from your nearest

authorized servicecenter.

This pruner requires replacement

blade

DWZPRB300.

1. Remove thebattery.

2. Wear proper eye protection and gloves and be careful

not to cutyourself.

3. Place the product on a smooth, levelsurface.

4. Using the blade lock knob

11

remove the cutting blade

screw

23

and nut

24

as shown in Fig.M.

5. Remove the cutting blade

8

as shown in Fig.M.

6. Install the new cuttingblade.

NOTE: Ensure the cutting edge faces toward the fixed

cutting blade as shown in Fig.M.

7. Insert the cutting blade screw

23

through the cutting

blade and into the nut

24

.

8. Use the blade lock knob

11

to fully tighten the cutting

blade screw

23

.

Blade Maintenance (Fig. N)



WARNING:

Use gloves and proper eye protection while

removing, sharpening, and installingblade.

The cutting blades are made from high quality, hardened

steel and with normal usage, they will not require

resharpening. However, if you accidentally hit a wire fence,

stones, glass, or other hard objects, you may put a nick in the

blade. There is no need to remove this nick as long as it does

not interfere with the movement of the blade. If you drop

the trimmer, carefully inspect it for damage. If the blade is

bent, housing cracked, handles broken or if you see any other

condition that may affect the tool's operation contact your

local authorized service center for repairs before putting it

back intouse.

1. Remove thebattery.

2. Remove blade from pruner. See instructions for

Removing and InstallingBlade.

3. Wear proper eye protection and gloves and be careful

not to cutyourself.

4. Secure blade

8

in a vise

25

as shown in Fig.N.

5. Carefully file the cutting edge

26

of the cutting blade

with a fine tooth file

27

(not included) or sharpening
