15
OPERATIONS MANUAL
REACH-INS & ROLL-INS
IMPORTANT NOTE: All freezers have a unique, energy
saving defrost cycle, as described above. As explained,
after defrost the automatic fan delay prevents evaporator
fans from operating until the coil has reached a preset
temperature, minimizing warm air circulation in the cab
net. During start-up and after a defrost cycle, fans will not
turn on immediately.
Settings should only be adjusted as noted, to minimize
electrical consumption and provide the most efficient
heating cycle. Contact the factory before making modifi-
cations to any settings not described above. Improper
adjustments can cause problems with your unit, includ-
ing loss of product and evaporator freeze ups, which are
not covered under warranty.
WARMER SYSTEM AND ADJUSTMENT
All Designer Line warming cabinets are designed with an operat-
ing range of 60°F to 180°F and factory performance run tested
to maintain an average cabinet temperature of 150°F. Always
preheat your new warming cabinet to the desired temperature
before placing any food into it. To operate, turn the thermostat
knob located on the upper grill panel, from the “off” position to
the desired cabinet temperature. When the desired temperature
is reached and displayed on the exterior thermometer, preheat-
ing is complete and the cabinet is ready to be loaded. Please
note that setting the thermostat higher than the desired tempera-
ture will not provide quicker preheat warm-ups.
delay switch. The system is time initiated by the defrost clock
and temperature terminated by an automatic limit switch. During
each defrost period, the condensing unit and evaporator fans go
off, while the defrost heater(s) are energized. After termination
of a defrost cycle, the heaters go off and the condensing unit
turns on. The evaporator fans remain off (for about 20 minutes)
until the coil is cools down to a preset temperature (typically
32°F). This defrost drip time, which allows any remaining water
to clear off the evaporator coil, also ensures that only cold air is
circulated throughout the storage compartment.
After your freezer has been properly installed and electrically
connected, the defrost clock should be set for the correct time of
day and desired defrost start time. Set the timer for one defrost
period per day, with a fail-safe cut-off time of 20 minutes, as
shown.
The time clock is located in the electrical control box, which has
a window that provides access to the timer dial. The scale on
the inner “120 MINUTE DIAL” indicates the maximum time in
minutes for the duration of each defrost period. The scale on the
outer “24 HOUR DIAL” represents the actual time of day.
To set the clock for the correct time, turn the knob at the center
of the dial counterclockwise until the current time of day, as
indicated by the scale on the outer dial, aligns with the arrow on
the “CURRENT TIME INDICATOR” in the upper left corner.
NOTE: If there is ever a loss of power to your freezer,
the clock must be reset for the correct time after power
is restored, to maintain the same time of day for defrost.
To set the start time for the daily defrost period, simply unscrew
the defrost pin located around the outer dial and screw it into the
threaded hole on the dial face at the desired time. Spare pins can
be placed in the storage slot located to the right side of the dial.
In some extreme applications, where there is very heavy usage,
excessively high humidity and/or constant door openings, addi-
tional defrost period(s) may be desired to ensure your evapora-
tor remains free of any frost accumulation. To add a defrost
period, simply remove a spare pin from the storage slot and
screw it into the threaded hole at the desired time on the dial.
A maximum of 3 defrost periods a day, with 8-hour intervals
between defrost periods, is acceptable.
