14
REACH-INS & ROLL-INS
OPERATIONS MANUAL
REFRIGERATION SYSTEM AND ADJUSTMENT
All self-contained refrigerators are designed and factory set to
maintain an average cabinet temperature of 38° to 40°F (3.3° to
4.4°C). The temperature control is accessible from the top of the
electrical console box located on the cabinet top behind the front
grill (see Figure 9, 9A & 9B). If an adjustment is necessary to
maintain the above temperature range only, place a screwdriver
into the thermostat slot and turn clockwise for a colder cabinet
temperature or counterclockwise for a warmer cabinet tempera-
ture. Further adjustments out of the factory design temperature
range must be made by a qualified refrigeration mechanic only.
IMPORTANT NOTE: All refrigerators are designed with an
automatic, “off-cycle” defrost system which means that
defrosting occurs automatically when the compressor
is not operating during an off-cycle. Do not set the ther-
mostat too cold where the cabinet temperature will fall
below 35°F because the evaporator will become blocked
by ice since the compressor off-cycle will be considerably
shortened. This will result in loss of food stored within
the cabinet and require service to defrost the evaporator
and re-adjust the thermostat.
FREEZER SYSTEM AND ADJUSTMENT
All self-contained freezers are factory set to maintain an average
cabinet temperature of -4° to 0°F (-20° to -18°C). These prod-
ucts are designed to hold pre-frozen food and although they are
capable of freezing small quantities of fresh food, they are not to
be used as fast or blast freezers. DO NOT ATTEMPT TO FREEZE
BULK QUANTITIES OF FRESH FOODS.
The temperature control is accessible from the top of the elec-
trical console box located on the cabinet top behind the front
grill (see Figure 5). If an adjustment is necessary to maintain
the above temperature range only on standard freezers, place
a screwdriver into the thermostat slot and turn clockwise for a
colder cabinet temperature or counterclockwise for a warmer
cabinet temperature. On low-temperature freezers, place a
screwdriver into the left thermostat adjustment screw (do not
turn the right differential adjustment screw) and turn clock-
wise for a colder cabinet temperature or counterclockwise for
a warmer cabinet temperature. Further adjustments out of the
factory design temperature range must be made by a qualified
refrigeration mechanic only.
DEFROST OPERATION
All freezer models are equipped with an automatic, electric
defrost system, consisting of evaporator coil defrost and drain
pan heater(s), a defrost time clock and temperature limit/fan
Once you see this, press on the front lower left to decrease
temperature displayed, or on the upper left section to increase
temperature displayed. After adjusting the offset, press the right
center of the front display again to exit calibration mode. Wait 10
to 15 seconds for the cabinet temperature to appear and recheck
the display calibration.
For example, if sensing device in the cabinet reads 38° and
thermometer displays 41°, press on the front right of the display
twice to show the current offset value. Then press the lower left
of the display three times to decrease offset by 3°. (If the original
offset value displayed was “0”, then “-3” will appear.)
ANTI-CONDENSATE CONTROL
All Continental upright models feature an anti-condensate door
heater switch, located on the front grill (see Figure 2, 2A &
2B). To save energy, move the switch to the OFF position to
deenergize the heaters around the perimeter of the cabinet door
openings. If you ever notice moisture accumulating on the face
of your cabinet, move the switch to the ON position to energize
the heaters. This will warm the face of the cabinet, eliminating
any condensation that may accumulate.
Refrigerators and freezers built after January, 2010 have an
energy saving thermal limit switch, mounted in the control box
(see Figure 9, 9A & 9B). This device automatically monitors
ambient conditions and turns the anti-condensate heaters off
whenever they are typically not required. The switch automati-
cally turns the heaters back on when the temperature rises to a
level when the additional heat is normally needed to eliminate
condensation.
Press here to decrease temp.
Press here for
calibration modePress here to decrease temp.
