13
OPERATIONS MANUAL
REACH-INS & ROLL-INS
(+/- 1°C). If it does not, use a small straight-blade screwdriver
to carefully pry the clear lens cover from the thermometer body
as shown (see Photo A).
Use a small straight-blade screwdriver and place on center
slotted hub of thermometer. Carefully hold the needle and turn
the center screw clockwise to lower and counterclockwise to
increase the desired temperature, as shown (see Photo B).
Replace the lens cover and recheck the calibration.
DIGITAL THERMOMETER AND CALIBRATION
Your NSF-approved thermometer has a remote sensing bulb,
located inside the cabinet on left-hand wall. The easy to read
24-Volt LED display is calibrated at the factory to accurately
show temperature at the center of the refrigerated compartment.
While in transit, your cabinet will be subjected to more jarring
and vibration than at any other time, and the thermometer may
require adjustment at start-up.
Refrigerators are designed to maintain 38° to 40°F (3.3° to
4.4°C); Freezers -2° to 0°F (-19° to -18°C). During periods of
heavy use, when doors are opened repeatedly or remain open
for an extended period, or if warm product is loaded into the
cabinet, the temperature displayed may temporarily exceed the
“normal” range. This is common, as warm air outside the cabi-
net mixes with cold air inside. If your thermometer continues
to display temperature above “normal” range, close the doors,
make sure they seal tight and keep them closed for at least 30
minutes. If a high temperature is still displayed, check the ther-
mometer by placing a pre-calibrated temperature sensing device
in the center of the refrigerated compartment and keep the
doors closed for at least 15 minutes. The thermometer display
should read the same temperature as the sensing device, within
+/-2°F (+/-1°C). If it does not, follow the instructions below to
calibrate the thermometer display, by adjusting the offset value
as required.
To calibrate, press on the right center of the front display twice
(see photo, next page). After the first press, “CAL” will appear
(unit is in calibration mode). After the second press, the tem-
perature offset value (-30 to 30) will appear.
NOTE: The buttons need to be pressed without delay
between actions. Contact the factory with any questions.
The system should run smooth and quietly in accordance
with generally accepted commercial standards. If any unusual
noises are heard, turn the unit off immediately and check for any
obstructions of the condenser or evaporator fans. Fan motors,
fan blades, or fan housings can be jarred out of position through
rough handling in transit or during installation.
REMOTE APPLICATIONS
All products are available for purchase as remote models, in
which case the condensing unit is not supplied with the cabinet.
All remote models come standard on 6” legs, with an expansion
valve in the evaporator housing, as well as stubs for the liquid
and suction refrigeration line connections. Installation of the
refrigeration accessories, condensing unit, and electrical hook-
up should be performed by qualified refrigeration personnel of
a competent refrigeration company only (see “Remote Set-Up
and Installation Guidelines” under “Optional Accessories”).
OPERATION
All cabinets must be given sufficient time to reach normal oper-
ating temperature before placing any product inside cabinet.
Refrigerators are designed to maintain an ideal cabinet tem-
perature of 38° to 40°F (3.3° to 4.4°C). Approximately 1 hour
of operation is required to reach this temperature. Freezers are
designed to maintain an ideal cabinet temperature of -4° to 0°F
(-20° to -18°C). Approximately 2 hours of operation are required
to reach this temperature.
DIAL THERMOMETER AND CALIBRATION
Your NSF-approved dial thermometer has a remote sensing bulb,
located in the refrigerated compartment. The display features a
large 2” diameter face, with any easy to read scale that shows
the internal cabinet temperature in Fahrenheit (°F) and Celsius
(°C). Blue (safe) and red (caution) color bands provide a quick,
visual indication of the temperature
inside your refrigerator or freezer. The
thermometer is pre-calibrated at the
factory, to accurately show the cabinet
temperature.
To check the accuracy of your ther-
mometer, place a pre-calibrated
temperature sensing device in the
center of the refrigerated compart-
ment and keep the door closed for at
least 10 minutes. The thermometer
should read the same temperature
as the sensing device, within +/-2°F
