CARE AND CLEANING
The hob itself does not warm up, so no food remains should get burnt on it. Therefore, you do not have to wait until
it cools down to clean the hob.
Do not use asteam cleaner or high-pressure cleaner to clean the appliance. Risk of damage to the hob!
• Clean the hob with aprotective and preservation agent specially designed for ceramic glass surfaces.
• For removal of food remains and other dirt, apply dirt repellent to the hob, which will facilitate cleaning of the
hob surface.
• Use only agents and repellents specially designed for ceramic glass surfaces.
• Never use coarse sponges, abrasive agents or aggressive cleaners (e.g. spray for cleaning ovens) or stain removers.
• Keep the control panel clean! Make sure the panel is always clean and dry.
• Food and water residues negatively aect the operation of the control panel; therefore it may not be fully
functional.
• Clean the hob after each cooking session. It will prevent the remains of food from burning during the next cooking
session.
• For cleaning the lukewarm hob use acleaning agent and apaper towel. Then wipe the hob with adamp cloth and
wipe it dry using asoft cloth.
• If the hob is cleaned while hot, stains could appear on it.
• Never leave residues of the cleaning agent on the hob; it could stain the glass surface.
• Metallic-gloss colouring appears after the use of unsuitable cleaners or abrasion of the cookware bottom.
• Its removal is very dicult. Use cleaning agents specially designed for ceramic glass surfaces.
• For the removal of food remains and alayer of grease use aspecial scraper for the glass.
• Clean the hob by placing the scraper at an acute angle and move the blade on the surface. Never use the handle
for cleaning the glass surface. Risk of scratches!
• WARNING! The glass scraper is very sharp! Risk of injury! If the edge is damaged, replace it immediately.
• After cleaning, secure the scraper again and keep it out of the reach of children.
INSTALLATION INSTRUCTIONS
• The warranty does not cover damages caused by incorrect installation.
• The responsibility for installing the appliance lies with the buyer, not the manufacturer.
• The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation.
• To ensure the correct function of the appliance, place it in asuitable furniture.
• The appliance should be assembled into correct built-in units and work surfaces that align to the standards and
have dimensions shown in Fig. 5.
• The kitchen furniture must be made of suciently heat-resistant material, at least 120 °C. The materials and
adhesives used must be resistant to heat from the appliance as according to the CSN EN 60335-2-6 standard.
Materials and adhesives that do not meet the stated standard may deform or peel-o.
Follow the following instruction during installation:
1. Remove all the covering and marketing materials from
the appliance before the rst use.
2. The required dimensions of the built-in space in the
worktop made of heat-resistant material of aminimum
thickness of 38–40 mm are on Fig. 5.
3. Leave min. 50 mm space for the adjacent cabinets on the
sides. Leave at least 50 mm free space behind the hob.
4. We recommend installing acook hood above the hob.
The cooking hood should be at least 600 mm above the
hob.
5. Aseparate cabinet without acooking hood should be at
least 760 mm above the hob (Fig. 6).
6. For sucient air circulation the appliance needs to be
installed as shown in Fig. 6 and the cabinet must be
designed so that the air can ow at the bottom. Make
sure that the ventilation space of 20 mm, between the
drawer and the rear wall and 50 mm between the drawer
and the hob, is free (Fig. 6).
7. Make sure that the ventilation space of 50 mm, between
the hob and the top of the below unit, is free.
8. If the appliance is installed above drawers make sure that
the space, between the bottom of the appliance and the
upper drawer, is 50 mm.
480
560
min. 50
min. 50
min. 50
Fig. 5
Fig. 6
