TRANSMIG 4RT INSTALLATION/SETUP
INSTALLATION/SETUP 3-14 Manual 0-5245
case actual welding voltage will be displayed, or (3) a period of 10 seconds elapses following the completion of
welding in which case the unit will return to preview mode.
In MIG mode when setting the INDUCTANCE value, the
light will illuminate, and the display will read
INDUCTANCE. The range of adjustment is from 0 to 100.
In TIG mode when setting DOWNSLOPE the SEC light will illuminate, and the display will read DOWNSLOPE. The
range of adjustment is from 0 to 10 seconds.
In Stick mode when setting the ARCFORCE the display will read ARCFORCE. The range of adjustment is from 0
to 100.
Arc force control provides an adjustable amount of welding force (or "dig") control. This feature can be particularly
beneficial in providing the operator the ability to compensate for variability in joint fit-up in certain situations with
particular electrodes. In general increasing the arc force control toward "100" (maximum arc force) allows greater
penetration control to be achieved. Arc force is increased by turning the control knob clockwise or decreased by
turning the knob anti-clockwise.
NOTE
The preview functionality provided on this power source is intended to act as a guide only. Some difference
may be observed between preview values and actual welding values due to factors including the mode of
welding, differences in consumables/gas mixtures, individual welding techniques and the transfer mode
of the welding arc (ie dip versus spray transfer). Where exact settings are required (in the case of proce
-
dural work), it is recommended that alternate measurement methods be utilized to ensure output values
are accurate.
15. Advanced Features
The TRANSMIG 350i, 450i and 550i have a series of Advanced features that allow the control of multiple parameters.
These are accessed by pressing the AMPS and VOLTS knobs at the same time.
Once in the Advanced Features mode, turn the AMP control to select the Parameter, and turn the VOLTS control
to adjust the value.
A-10633
Figure 3-2: Advanced Features
