OPERATING MANUAL BLUEVENOM 4R-ROVER
CIGWELD.COM.AU | 29
D
MEMORY FUNCTION
MEMORY RECALL
To recall welding parameters from the stored Memory,
press the Memory button to select Memory Recall. The
Memory Recall indicator will illuminate when selected. The
Left Digital Display shows RCL and the Right Digital Display
shows the Memory location.
Turn the Right Control Knob to select a Memory location
from 1 to 5 that can be recalled. Conrm by pressing the
Right Control Knob to Recall the stored Memory from that
location.
MEMORY SET
To recall welding parameters from the stored Memory,
press the Memory button to select Memory Recall. The
Memory Recall indicator will illuminate when selected. The
Left Digital Display shows LOD and the Right Digital Display
shows the Memory location.
Turn the Right Control Knob to select a Memory location
from 1 to 5 that can be recalled. Conrm by pressing the
Right Control Knob to Recall the stored Memory from that
location.
Note: Initial factory settings are loaded into the Memory
Locations which can be overwritten when new user settings
are required.
LEFT CONTROL KNOB
Press to step through available options in each Process;
Once desired function selected turn Left Control Knob
clockwise to increase or counterclockwise to decrease value.
• Turn the Left Control Knob to make selection or change
values and press to conrm. To select an option from the
displayed menu:
• Options will be highlighted in sequence at every turn;
• Turn clockwise or anti-clockwise to change selection;
• Press Control Knob to conrm the selection or to enter the
next option on menu.
MIG Quickset Mode:
QuickSet Plate Thickness, Wire
Diameter, Material, and
Wire Feed Speed
MIG Manual Mode:
Wire Feed Speed only
WIRE INCH BUTTON
Hold button depressed to Feed the MIG Wire through the MIG
Gun. When Wire Inch Button depressed INC will appear on the
Left Digital Display. Whilst button is held depressed wire speed
will start at minimum speed and ramp up to maximum speed
and maintain maximum speed whilst the button is depressed.
