Chroma-Q
®
Color Force II Plus User Manual V1.1 8 July 2024
www.chroma-q.com
4.2. Grouping Options
Color Force II Plus ™ offers a powerful, wide variety of grouping options for the individual cells (or
pixels) within each fixture. Grouping is independent of control Mode selection. A Color Force II Plus
72
TM
fixture consists of 24 cells, a Color Force II Plus 48
TM
fixture consists of 16 cells and a Color
Force II Plus 12
TM
fixture consists of 4 cells. “Cell” or pixel grouping allows individual control of each
single cell or various grouping of cells as defined in the tables below. In “x24/x16/x4” grouping, all
cells in the Color Force II Plus
TM
72/48/12, the fixtures will be controlled as 1 group. In p14-x1 each cell is
being controlled independently for a total of 24, 16 or 4 individual cells for the Color Force II
Plus
TM
72, 48 or 12 respectively. See tables below where the number in the table indicates the group
number. In RGBA Mode each group uses 4 DMX slots; in RGB & HSI Modes each group uses 3
DMX slots.
Od / Ev: Controls every other cell (pixels) in two groups of control – odd cell and even cells.
Skp2: Provides control of three groups comprising every third cell (pixel) on the fixture.
Skp3: Provides control of four groups comprising every forth cell (pixel) on the fixture.
Skip6: Provides control of six groups comprising every sixth cell (pixel) on the fixture.
Grouping & DMX Addressing
Grouping: Color
Force II Plus 72
TM
Flip:
L→R
Group
Select
ed
Group Number(s)
x24
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
x12
1
1
1
1
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
2
2
2
2
x8
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
3
3
3
3
3
3
3
3
x6
1
1
1
1
1
1
2
2
2
2
2
2
3
3
3
3
3
3
4
4
4
4
4
4
x4
1
1
1
1
2
2
2
2
3
3
3
3
4
4
4
4
5
5
5
5
6
6
6
6
x3
1
1
1
2
2
2
3
3
3
4
4
4
5
5
5
6
6
6
7
7
7
8
8
8
x2
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
x1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Od/Ev
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
Skp2
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
Skp3
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
Skp6
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
4
5
6
1
2
3
4
5
6
Grouping: Color Force II
Plus 48
TM
Flip:
L→R
Group
Selected
Group Number(s)
X16
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
x8
1
1
1
1
1
1
1
1
2
2
2
2
2
2
2
2
x4
1
1
1
1
2
2
2
2
3
3
3
3
4
4
4
4
x2
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
x1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Od/Ev
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
Skp3
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
Skp7
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
