Chroma-Q
®
Color Force II Plus User Manual V1.1 7 July 2024
www.chroma-q.com
Mode
4.1. Mode Select Options
RGBA (Red, Green, Blue and Amber) provides 4 control channels that directly affect the intensity of
each color within a group. Color is mixed by adjusting the levels of each of the four channels. The
DMX footprint will be determined by the grouping option selected. White (of about 4,000K) is
achieved with all channels at full. Refer to the table below for detail on grouping and DMX footprints.
This mode assigns 4 DMX channels to set Red, Green, Blue and Amber levels in each cell, or group of
cells.
To set the fixture to RGBA mode,
1.
On the Main Menu, tap Mode
2.
On the Mode screen, tap RGBA
3.
Tap Apply to save or Escape to cancel
RGB (Red, Green, Blue with *Magic Amber™) gives 3 control channels directly affecting the intensity of
the corresponding group. Color is mixed by adjusting the levels of the three primary colors in each group.
The DMX footprint will be determined by grouping option selected. White is achieved with all channels
at full including Magic Amber.
To set the RGB mode,
1.
On the Main Menu, tap Mode
2.
On the Mode screen, tap RGB
3.
Tap Apply to save or Escape to cancel
HSI (Hue, Saturation and Intensity) gives 3 control channels to each group; 2 color channels for hue
and saturation and one intensity channel. A separate definable intensity channel is particularly useful
when creating intensity chases or when the grand master is used. The hue channel has 255 different
colors available and the saturation channel specifies the saturation level of that color. The saturation
channel is fully saturated at full. White is achieved with the intensity channel to full and the saturation
channel at zero.
*Magic Amber is the term used for the unit's ability to bring in amber when mixing colors that require
it.
Look Sel (Look Select) gives 1 control channel to select a preset look based on the DMX value. Refer
to the table below for factory presets.
MASTER sets the fixture to output a DMX stream for control of any fixtures connected “downstream”.
Strobe options
Pixel Ordering Options
Mode Select options
Grouping options
Apply Changes/Save
Cancel / Go Back
