BOLERO DRESSCODE 6150 INVERTER A

BOLERO DRESSCODE 7150 INVERTER A

BOLERO DRESSCODE 7150 INVERTER STEEL A

BOLERO DRESSCODE 6150 INVERTER A

BOLERO DRESSCODE 7150 INVERTER A

BOLERO DRESSCODE 7150 INVERTER STEEL A

107106

ENGLISH ENGLISH

professional service personnel. If the plug does not match the socket, do not change it

yourself.

- Once the washing machine emits smoke or an odour, turn o the power and contact

technical support service.

- The appliance must be connected to a water inlet. Use new hoses instead of old ones.

- To ensure quality, water injection tests are carried out before the washing machine leaves

the factory, so it is normal that water may be present inside the drum, door seals and door

panel.

Water inlet connection

1. The water supply pressure must be between 30kPa and 1000kPa.

2. Do not scrape the screw thread when connecting the inlet hoses to the valves.

3. If the water supply exceeds 1000kpa, install a pressure regulator.

- Two seals are provided on the connectors at both ends of the hose to prevent water

leakage (Figure 5).

- Open the tap and check the connectors for leaks.

- Check the hoses regularly. Make sure that the hoses are not kinked or intertwined.

Connection of inlet hose and taps

Figure 6

Check the rubber seals on both sides of the hose, insert a rubber seal into the threaded ttings

of each hose.

Fig. 6 key:

1. Rubber seal

2. Water hose

Figure 7

Connect the water supply hoses to the water taps rmly by hand and then tighten another 2/3

turn with pliers. Connect the blue hose to the water tap.

Figure 8

After connecting the inlet hose to the water taps, open the water taps to remove foreign

substances (dirt, sand or sawdust) from the hoses. Let the water drain into a bucket and check

the water temperature.

Figure 9

Connect the hoses to the water inlet rmly by hand and then tighten another 2/3 turn with

pliers.

Do not over-tighten the hoses as this could damage the valves and cause leaks. Check for leaks

- The bolts must be retted when the appliance is transported again.

4. Use the provided caps to seal the screw holes.

Correct installation (Fig. 4)

Horizontal adjustment:

The angle of inclination must be less than 1 degree.

Fig. 4 key:

1.- Drain hose

2.- 2 cm distance (approx)

Power socket

- The distance between any side of the washing machine and the power socket must be 1.5

metres.

- Do not use too many electrical appliances in one socket.

Cleaning up the surroundings

- The wall, door and oor need to be cleaned.

- Install the washing machine on a hard, stable oor with a oor drain instead of a soft

carpet or wooden oor.

- Do not place laundry or other items on top of the appliance, otherwise it may aect the

normal operation.

Electric connection

1. Do not use a multiple adapter or similar.

2. After using the washing machine, switch o and close the tap.

3. Connect the washing machine to an earthed socket so that it corresponds to the wiring

principles.

4. Place the washing machine where the drain hose connection is easy.

- Contact the technical support service and ask professionals to install the washing machine.

Non-specialists can cause damage and problems in the washing machine.

- Do not place the washing machine in a place where the temperature is below zero. Pipes

will freeze and burst. In addition, temperature below zero will damage the knob and

buttons.

- If you transport the appliance in an environment where the temperature is below freezing,

then keep the appliance at room temperature for a few hours before starting it.

Earthing

- The washing machine must be connected to an earthed socket. Should a problem occur,

the appliance can reduce the risk of electric shock. This appliance is equipped with a cable

that includes a wire and a grounded plug. The earthed plug must be plugged into a suitable

socket outlet. If you want to know if the appliance is properly grounded, contact your
