ENGLISH ENGLISH

- In case the distance is longer, this will aect the draining process of the dishwasher,

causing too much waste water to accumulate in the hose, thus aecting the performance

of the dishwasher.

- If an extension is necessary, it is recommended that it is heat resistant to chemicals such

as detergents.

- Before connecting the dishwasher, check that the hose is properly installed, unobstructed

and free of water leaks. Otherwise, the control panel display may show the E2 error.

Warning:

Carefully pass the drain hose through the hole in the furniture (if applicable), as the furniture

may have sharp edges that could damage the hose. Sharp edges should be covered to ensure

that they do not damage either the drain hose or the water supply hose.

Connection method 1

If the drain hose is connected to the drain pipe of a sink, it should be arched upwards and xed

to the underside of the worktop.

Please note:

To ensure that the water is drained optimally, install the hose as shown in gure 13.

Connection method 2

- When the drain hose is connected to a separate pipe riser (1), it must be ensured that the

connector (2) is completely watertight. Otherwise, it may cause unpleasant odours.

- The diameter of the pipe riser shall be at least 40 mm.

Please note:

To ensure that the water is drained optimally, install the hose as shown in gure 14.

Connecting the water inlet hose to a tap

The seal must be tted to the water inlet hose. Always use the provided hose. To ensure their

quality, all dishwashers are tested before leaving the factory, so it is normal for some water to

be present inside the dishwasher.

Tips:

1. The water supply pressure must be between 30 kPa and 1000 kPa.

2. Try not to damage the thread when connecting the water inlet hose to the inlet valve.

3. If the water supply pressure exceeds 1000 kPa, install a pressure reducing valve (not

included).

4. Open the tap and check for water leaks at the connector and/or hose.

5. Check the hose regularly and replace it if it is found to be deteriorated.

6. Make sure that the hoses are not damaged or criss-crossed.

Warning:

- If any wooden furniture is in contact with the dishwasher, it is advisable to varnish it with

waterproof paint to prevent moisture or possible water leaks from spreading.

- Place the dishwasher in the recess provided and make sure that the drain hose, located at

the rear of the dishwasher, is free of any kinks or obstructions.

- Place the dishwasher on a at oor. Do not place any objects between the oor and the

feet of the dishwasher.

Tips:

- Open the door and pull the top of the dishwasher carefully to move or lift it, as shown in

Figure 11. Exercise extreme caution to avoid possible damage to the appliance or personal

injury.

- Do not push the door of the dishwasher with your knees to close it but push it gently with

your hand.

- Do not pull on the door to move or lift the dishwasher; doing so may damage the door or

hinge.

Removing the top cover (Fig. 12)

If the height of the cabinet in which the dishwasher is to be placed is less than 850 mm, you can

remove the top cover by following the steps below:

1. Use a suitable tool to press the two fasteners of the top cover together.

2. Lift the top cover and remove it.

IMPORTANT:

IF YOU REMOVE THE TOP COVER, THE APPLIANCE WARRANTY WILL NOT COVER DAMAGE

DIRECTLY CAUSED BY NOT HAVING THE TOP COVER, E.G. DAMAGE TO INTERNAL COMPONENTS

DUE TO SPILLAGE OF WATER OR LIQUIDS INSIDE THE APPLIANCE.

Connecting water and electricity supplies

- The connection of the water and electricity supplies must only be carried out by a qualied

technician.

- The dishwasher must not be placed on top of the water hoses or the power supply cable.

- The appliance must be connected to the water supply network by means of new hoses. Do

not use old hoses.

Drain hose connection

ATTENTION:

- Please note that the drain hose cannot be disconnected, so the outlet must be xed and

as close as possible to the dishwasher. The drain hose must be at a maximum distance of

1~1.5 metres from the dishwasher.
