Fig. 1 — 48GE 17-28 Model Number Nomenclature (Example)
Model Series - WeatherMaster
®
GE — Mid Tier Puron Advance™
Unit Heat Type
48 — Gas Heat Packaged Rooftop
Cooling Tons
17 = 15.0 tons
20 = 17.5 tons
24 = 20.0 tons
28 = 25.0 tons
Heat Options
D = Low Heat
E = Medium Heat
F = High Heat
S = Low Heat w/ Stainless Steel Heat Exchanger
R = Medium Heat w/ Stainless Steel Heat Exchanger
T = High Heat w/ Stainless Steel Heat Exchanger
Sensor Options
A = None
B = Return Air Smoke Detector (RA)
C = Supply Air Smoke Detector (SA)
D = RA + SA Smoke Detector
J = Condensate Overflow Switch
K = Condensate Overflow Switch + RA Smoke Detectors
L = Condensate Overflow Switch + RA and SA Smoke Detectors
M = Condensate Overflow Switch + SA Smoke Detector
Indoor Fan Options - Vane Axial EcoBlue Fan System
2 = Standard/Medium Static Motor
3 = High Static Motor
5 = Standard/Medium Static Motor and Filter Status Switch
6 = High Static Motor and Filter Status Switch
J = High Static Motor - Horizontal Supply
L = High Static Motor - Horizontal Supply and Filter Status Switch
Refrig. Systems Options
M = Two Stage Cooling/Single Circuit
N = Two Stage Cooling/Single Circuit with
Humidi-MiZer
®
System
P = Two Stage Cooling/Single Circuit with
Head Pressure Control
X = Two Stage Cooling/Single Circuit with
Chicago Code Relief Valve
Y = Two Stage Cooling/Single Circuit with
Humidi-MiZer
®
System and Chicago Code Relief Valve
Z = Two Stage Cooling/Single Circuit with
Head Pressure Control and Chicago Code Relief Valve
Coil Options – RTPF (Outdoor – Indoor – Hail Guard)
A = Al/Cu – Al/Cu
B = Precoat Al/Cu – Al/Cu
C = E-coat Al/Cu – Al/Cu
D = E-coat Al/Cu – E-coat Al/Cu
M = Al/Cu – Al/Cu – Louvered Hail Guard
N = Precoat Al/Cu – Al/Cu – Louvered Hail Guard
P = E-coat Al/Cu – Al/Cu – Louvered Hail Guard
Q = E-coat Al/Cu – E-coat Al/Cu – Louvered Hail Guard
R = Cu/Cu – Al/Cu – Louvered Hail Guard
S = Cu/Cu – Cu/Cu – Louvered Hail Guard
Voltage
1 = 575-3-60
5 = 208/230-3-60
6 = 460-3-60
Design Revision
- = Factory Design Revision
Base Unit Controls
0 = Electromechanical Controller
3 = SystemVu™ Controller
8 = Electromechanical Controls with POL224
EconomizerONE (with FDD
b
)
Intake / Exhaust Options
A = None
B = Temperature Economizer with Barometric Relief
F = Enthalpy Economizer with Barometric Relief
L = ULL (Ultra Low Leak) Temperature Economizer
with Barometric Relief and CO
2
Sensor
M = ULL Enthalpy Economizer with Barometric
Relief and CO
2
Sensor
N = ULL Temperature Economizer with Power Exhaust
and CO
2
Sensor, Vertical Only
P = ULL Enthalpy Economizer with Power Exhaust
and CO
2
Sensor, Vertical Only
U = ULL Temperature Economizer with Barometric Relief
V = ULL Temperature Economizer with Power Exhaust,
Vertical Only
W = ULL Enthalpy Economizer w ith Barometric Relief
X = ULL Enthalpy Economizer with Power Exhaust,
Vertical Only
Packaging Compliance
0 = Standard
Example:
Position:
48GEEM20A2A6 - 0A0A0
123456789101112131415161718
Electrical Options
A = None
B = HACR Breaker
C = Non-Fused Disconnect (NFDC)
N = Phase Monitor/Protection (PMR)
P = PMR + HACR
Q = PMR + NFDC
1 = HSCCR
a
(High Short Circuit Current Rating)
Protection
Service Options
0 = None
1 = Unpowered Convenience Outlet (NPCO)
2 = Powered Convenience Outlet (PCO)
3 = Hinged Panels (HP)
4 =
Hinged Panels + NPCO
5 = Hinged Access Panels + PCO
6 = MERV-13 Filters (M13)
7 = NPCO + MERV-13 Filters
8 = PCO + MERV-13 Filters
9 =
Hinged Panels +
MERV-13 Filters
A = HP + NPCO + MERV-13 Filters
B = HP + PCO + MERV-13 Filters
C = Foil Faced Insulation (FF)
D = FF + NPCO
E = FF + PCO
F = FF + HP
G = FF + HP + NPCO
H = FF + HP + PCO
J = FF + MERV-13 Filters
K = FF + NPCO + MERV-13 Filters
L = FF + PCO + MERV-13 Filters
M = FF + HP + MERV-13 Filters
N = FF + HP + NPCO + MERV-13 Filters
P = FF + HP + PCO + MERV-13 Filters
NOTE(S):
a
Not available on the following models/options: 575V, Head
Pressure Control, Phase Loss Monitor,Non-Fused Disconnect,
HACR Breaker, Powered Convenience Outlet.
b
FDD (Fault Detection and Diagnostic) capability per California
Title 24 section 120.2
