4
Table 2 — Physical Data — 39SV Coil and Filter Data
39SV UNIT SIZE 02 03 04 05 07 09
CHILLED WATER
Nominal Capacity at 400 fpm (cfm) 1200 1200 1600 2000 2932 3668
Face Area (sq ft) 3 3 4 5 7.33 9.17
Coil Connection Size (in. OD sweat) 3/4 3/4 7/8 1-1/8 1-1/8 1-3/8
HOT WATER
Nominal Capacity at 400 fpm (cfm) 804 804 964 1276 2292 3124
Face Area (sq ft) 2.01 2.01 2.41 3.19 5.73 7.81
Coil Connection Size (in. OD sweat) 7/8 7/8 7/8 1-1/8 1-1/8 1-1/8
DIRECT EXPANSION
Nominal Capacity at 400 fpm (cfm) 1200 1200 1600 2000 2932 3668
Face Area (sq ft) 3 3 4 5 7.33 9.17
Connection Size (in. OD sweat)
Liquid Line (Qty) 3/8 3/8 1/2 1/2 5/8 1/2 (2)
Suction Line (Qty) 3/4 3/4 7/8 1-1/8 1-1/8 7/8 (2)
STEAM
Nominal Capacity at 400 fpm (cfm) 624 624 688 1268 1750 2452
Face Area (sq ft) 1.56 1.56 1.72 3.17 4.375 6.13
FILTER DATA
Size (in.) (Qty) 20x20 20x20 22.5x22.5 16x25 (2) 20x25 (4) 20x25 (4)
Nominal Face Area (sq ft) 2.78 2.78 3.52 5.56 13.89 13.89
Table 3 — Physical Data — 39SM Coil and Filter Data
39SM UNIT SIZE 04 05 07 09 13 17
CHILLED WATER
Nominal Capacity at 400 fpm (cfm) 1668 2084 2776 3332 5000 7084
Face Area (sq ft) 4.17 5.21 6.94 8.33 12.5 17.71
Coil Connection Size (in. OD sweat)
4-Row (Qty) 7/8 1-1/8 1-1/8 1-3/8 1-3/8 1-5/8 (2)
6-Row (Qty) 1-1/8 1-1/8 1-3/8 1-5/8 1-5/8 1-5/8 (2)
HOT WATER
Nominal Capacity at 400 fpm (cfm) 1668 2084 2776 3332 5000 7084
Face Area (sq ft) 4.17 5.21 6.94 8.33 12.5 17.71
Coil Connection Size (in. OD sweat)
2-Row (Qty) 7/8 1-1/8 1-1/8 1-1/8 1-1/8 1-1/8 (2)
4-Row
a
(Qty) 7/8 1-1/8 1-1/8 1-3/8 1-3/8 1-5/8 (2)
6-Row
a
(Qty) 1-1/8 1-1/8 1-3/8 1-5/8 1-5/8 1-5/8 (2)
DIRECT EXPANSION
Nominal Capacity at 400 fpm (cfm) 1668 2000 2668 3332 5000 7000
Face Area (sq ft) 4.17 5 6.67 8.33 12.5 17.5
Connection Size (in. OD sweat)
Liquid Line (Qty) 1/2 1/2 5/8 5/8 5/8 5/8 (2)
Suction Line (Qty) 7/8 1-1/8 1-1/8 1-3/8 1-3/8 1-5/8 (2)
STEAM
Nominal Capacity at 400 fpm (cfm) 1492 1960 2472 3028 4752 6700
Face Area (sq ft) 3.73 4.9 6.18 7.57 11.88 16.75
FILTER DATA
Size (in.) (Qty) 20x25 (2) 20x25 (2) 16x25 (4) 16x25 (4) 16x20 (2)
20x20 (2)
16x25 (2)
20x25 (2)
16x20 (2)
20x20 (2)
16x25 (2)
20x25 (2)
Nominal Face Area (sq ft) 6.94 6.94 11.11 11.11 22.5 22.5
NOTE(S):
a. 4 and 6 row hot water coils have the same face area as 4 and 6 row chilled water coils.
