13
Table 2 — Section Dimensions and Weights
LEGEND
SECTION DIMENSIONS (in.) AND WEIGHTS (lb)
Nominal cfm at 500 fpm 1,500 3,000 4,000 5,000 6,000 7,500 9,000 10,500 12,500
Unit Size 03 06 08 10 12 15 18 21 25
Height (in.) LA, LB, LC, LG 24.3 28.2 32.1 32.1 32.1 40.0 43.9 43.9 43.9
Height (in.) LD, LF, LH 45.5 53.3 61.3 61.3 61.3 76.9 84.8 84.8 100.6
Width (in.) 37.9 45.8 49.7 57.6 65.1 65.1 65.1 77.3 77.3
ITEM
NO.
a
NOTE(S):
a. Item numbers refer to Fig. 9.
DESCRIPTION
AWL (in.)
Weight (lb)
b
b. Unit weights do not include coils and motors.
1 39LA
40.9 48.8 56.7 56.7 56.7 72.4 80.3 80.3 76.4
200 280 411 470 540 620 695 740 820
2 39LB
29.1 33.1 37.0 37.0 37.0 44.9 48.8 48.8 56.7
150 210 308 352 405 465 521 555 615
3 39LC
37.0 40.9 44.9 44.9 44.9 52.8 56.7 56.7 64.6
170 238 349 400 459 527 590 629 697
4 39LD
21.3 25.2 29.1 29.1 29.1 37.0 40.9 40.9 48.8
230 322 472 540 621 713 799 851 943
5 39LF
21.3 25.2 29.1 29.1 29.1 37.0 40.9 40.9 48.8
230 322 472 540 621 713 799 851 943
6 39LG
21.3 25.2 29.1 29.1 29.1 37.0 40.9 40.9 48.8
120 168 246 282 324 372 417 444 492
7 39LH
21.3 25.2 29.1 29.1 29.1 37.0 40.9 40.9 48.8
220 308 452 517 594 682 764 814 902
ACCESSORIES
Unit Size 03 06 08 10 12 15 18 21 25
Height (in.) 24.3 28.2 32.1 32.1 32.1 40.0 43.9 43.9 43.9
Width (in.) 37.9 45.8 49.7 57.6 65.1 65.1 65.1 77.3 77.3
ITEM
NO.
a
DESCRIPTION
AWL (in.)
Weight (lb)
b
8 Mixing Box Section
27.6 27.6 27.6 27.6 27.6 27.6 35.4 35.4 35.4
139 164 193 219 226 244 283 272 311
9 Filter Mixing Box
27.6 27.6 27.6 27.6 27.6 27.6 35.4 35.4 35.4
150 173 208 227 245 279 327 340 395
10 Flat Filter Section
7.9 7.9 7.9 7.9 7.9 7.9 7.9 7.9 7.9
37 43 48 50 55 74 75 86 90
11 Angle Filter Section
19.7 19.7 19.7 19.7 19.7 19.7 19.7 19.7 19.7
75 82 97 107 114 134 140 159 185
12 Access Section
19.7 19.7 19.7 19.7 19.7 19.7 19.7 19.7 19.7
48 55 60 64 68 74 77 87 92
13
Preheat (Hot Water or
Steam) Section
7.9 7.9 7.9 7.9 7.9 7.9 7.9 7.9 7.9
36 42 43 46 49 52 54 53 57
14 Preheat (Electric) Section
19.7 19.7 19.7 19.7 19.7 19.7 19.7 19.7 19.7
49 56 61 66 72 74 76 87 89
AWL — Airway Length
