32
ENG
iJW +0300103EN rel. 1.1 - 31.03.2025
Index
Functions enabled/disabled in OFF status
Function Enabled Disabled
Compressor control (off and pump down valve closed)
z
Dead band control
z
Auxiliary compressor control with and without rotation
z
Defrost
z
Evaporator fan control
z
Humidity control
z
Continuous cycle
z
Condensing fan control (if enabled)
z
Logs
z
Low temperature alarm LO
z
High temperature alarm HI
z
Immediate alarm from external contact IA
z
Delayed alarm from external contact dA
z
Defrost ended due to timeout alarm Ed1, Ed2
z
Pump down ended after maximum time alarm Pd
z
Low pressure alarm from external contact LP
z
Autostart in pump down alarm AtS
z
High condenser temperature warning and alarm cht, CHt
z
Open door alarm dor
z
Frost protection alarm AFr
z
Type HA and HF HACCP alarm
z
Buzzer (off ) and alarm relay (non-alarm status)
z
HACCP control
z
Defrost according to scheduled time bands
z
Timed defrost (timer “dI” updated)
z
Defrost from digital input (if enabled)
z
Defrost from keypad and supervisor
z
High and low power supply voltage alarm EHI and ELO
z
Generic alarm with high threshold GHI and GLO
z
Refrigerant leak alarm rSF
z
Maintenance request SrC
z
Parameter setting and display
z
Auxiliary relay on/off
z
Autostart compressor in pump down (if enabled)
z
Door switch limited to light management
z
Control probe error alarm rE
z
Probe error alarm E1, E2, E3, E4
z
Clock not updated (if featured) alarm Etc
z
Confi guration not terminated correctly alarm SF
z
Confi guration write error CE
z
Light or aux on/off based on scheduled time bands
z
Set point changed based on scheduled time bands
z
Tab. 7.a
Notice: in Off status, the defrost interval dI is always updated, in order to maintain the cyclical nature of this interval. If a de-
frost interval expires when the unit is off , the event is recorded and, when the unit is switched on, a defrost request is generated.
The transition from On to Off occurs as follows:
• the compressor protection times are observed;
• pump down is performed (if enabled);
• defrosting is forcibly terminated and will not resume when switching On;
• the continuous cycle is forcibly terminated and will not be resumed when switching On.
The transition from Off to On occurs as follows:
• the compressor protection times are observed;
• defrosting is not performed at start-up (if enabled), this in fact refers to power-on;
• the compressor and fan delay at start-up c0 is not set, and refers to power-on.
7.2 Inputs and outputs
The iJW controller has a maximum of 3 analogue inputs, 2 digital inputs and 1 multifunction input. In addition, on some models,
an additional analogue input is available for connecting a humidity probe. iJW has a maximum of 6 digital outputs. See “De-
scription of the terminals”. NTC, PT1000, PTC, NTC HT or NTC LT temperature probes can be connected to the analogue inputs; all
probes must be the same type. See the parameter table.
Analogue inputs
Size Code
Probes
Passive Active
NTC
(–50T90 °C)
Pt1000
(–60T120 °C)
PTC
(–50T150 °C)
NTC HT
(–40T150 °C)
NTC LT
(–80T105 °C)
0 to 5 V ratiom-
etric
SMALL IJWPSA**01***** YES YES YES YES YES NO
IJWPSA**02***** YES YES YES YES YES NO
IJWPSA**07***** YES YES YES YES YES YES
LARGE IJWPLA**01***** YES YES YES YES YES NO
IJWPLA**02***** YES YES YES YES YES NO
IJWPLA**07***** YES YES YES YES YES YES
Tab. 7.b
