cnReach N500 User Guide System Configuration
phn-4980_001v004 August 2019)
2-4
Navigating the User Interface
After connecting the IP address of the radio, the user will be prompted to login with a username and
password. The defaults are:
Username: admin
Password: admin
After successfully login, the home page will be displayed similar to the example below. The navigation
bar is on the left and is used to connect to all of the different configuration and troubleshooting features
on the radio. The remainder of this chapter follows the navigation bar in order with sample screens of a
typical 900 Mhz licensed Point to Multipoint network. Where significant differences exist between band
(900, 700, 450, 200) or in licensed vs. unlicensed, they will be called out. Otherwise, the GUI and
features are the same for each band.
Attention
At the bottom of pages that allow for configuration changes there is both a ‘Save’ button
and a ‘Commit’ button. The user MUST click save on each page after making a change and
BEFORE navigating to a new page. Clicking COMMIT will commit all changes to memory
and initiate a re-boot of the unit if necessary.
