Je bekijkt pagina 165 van 320

L2 Features 165

Unicast MAC Learning Status : Enable

Customer-VLAN : 10

Port Gi0/2

Port Type : Provider Network Port

Service VLAN Classification : PVID

cnMatrix# show service-vlan

Customer-VLAN Id Registration Table

Service VLAN Port Customer-VLAN S-VLAN Priority

1000 Gi0/1 ALL NONE

Provider-edge Port Configuration

Service VLAN Port PVID Default Prio

1000 Gi0/1 NONE 5

Configuration example

1. Configure global settings:

cnMatrix# boot default bridge-mode provider-edge

The switch reboots to the default configuration, in “provider-edge” mode.

Configure port modes:

cnMatrix(config)# interface gigabitethernet 0/1

cnMatrix(config-if)# bridge port-type customer-edge

default is provider, so for the other ports, we do not have to configure anything.

2. Create S-VLANs

cnMatrix(config)# vlan 100

cnMatrix(config)# vlan 102

cnMatrix(config)# vlan 103

S-VLANs must be created before assigning customer-Vlans to them.

3. Map Customer VLANs to SVANs

cnMatrix(config-if)# switchport customer-vlan 2 service-vlan 102

cnMatrix(config-if)# switchport customer-vlan 3 service-vlan 103

cnMatrix(config-if)# switchport service-vlan 100

Traffic from VLAN 2 will go to S-VLAN 102, traffic from VLAN 3 will go to S-VLAN 103. All other

traffic will go to S-VLAN 100.

4. Configure the dot1p priority in the S-VLAN.

This is configured at the ingress of the customer port, and will be visible at egress on any provider

port:
