AWT35-100109 Rev AB 21/29
CAL.P0, and 0 will be displayed. Press the UNIT key for more than 2.5s to change the
calibration unit.
6. Press the TARE key to store the Zero Calibration Point.
CAL.P1, and the scale capacity will be displayed.
7. Use the
↑ ↓ → keys to change the CAL.P1 weight value (>10% of the scale capacity)
8. Place the certified weight over the scale platform.
9. Press the TARE key to store the CAL.P1 Point.
10. Press the TARE key to save the calibration points and exit the Calibration mode or, press the PRINT
key to add CAL.P2/3 points.
On calibration complete, the indicator will reboot and return to general weighing mode.
If there’s an error occurred in calibration, the message “CAL.Er” is displayed. Repeat steps 5 to 9 to
adjust the calibration points.
5.4 Service Configuration Menus
The SBI 210-LCD is configured from the factory to match the specified settings for each unit, as defined
by the product specifications and sales brochure. Modification of the SBI 210-LCD Indicator settings
can be accomplished by altering the configuration settings in the Config Menu.
The configuration and test of your scale should be accomplished by a trained service
technician.
5.4.1 Configuration Options
Press and hold the HOLD key then turn the indicator on by pressing the ZERO/ON/OFF keys.
Release the ZERO/ON/OFF key when the display lights.
Release the HOLD key when the message “CONFIG” pops up to open the Configuration Menu.
The number of time that the indicator has been configured is displayed.
Navigate the menu using the keys, press the TARE key to confirm or the ZERO/ON/OFF
key to cancel the operation / exit the menu.
CONFIG
SubMenu1
SubMenu2
Option
Default
Description
RESET YES / NO NO
Resets the configuration to factory
setting.
REGULA
NONE
NONE
Sets settings to local regulations.
USA
CANADA
EUROPE
PRIM.N
100~
100000
2000
Sets the number of divisions (div) of the
primary unit of measure (lb).
