AWT35-501860 Issue AE.1 Page 10
2.3. Battery Operation
The SBI-110 can be operated from a 6V 4Ahrs battery located inside the indicator or plugged into an
acceptable power outlet. Battery life is approximately 107 hours with the backlight off.
When the battery needs charging this symbol, , appears in the upper left corner of the weight
display. The scale will still operate for about 10 hours after which it will automatically switch off to
protect the battery.
When the scale is turned on, the battery status is:
- Green LED, the battery is fully charged;
- Red LED, the battery is low and needs to be recharged.
Do not use any other type of power adaptor other than the one supplied with the scale and verify that
the AC power socket outlet is properly protected.
Charge the battery before using (+12hrs).
2.4. Powering ON/OFF the Scale
With the platform connected and the battery fully charged or the charger plugged into the indicator,
press the ON key to power ON the scale. A display test will be performed on power up and the scale
will finish in normal weighing mode. Press the OFF key to turn the scale off.
2.5. Front Panel
The indicator has a sealed keypad and a 6 digits LCD display 0.59” (40mm) high with a white
backlight. Only the active annunciators are shown below.
2.5.1. Display Annunciators
Display reading is stable
Scale at Zero
NET
Indicates a Net weight
GROSS
Indicates a Gross weight
Under acceptable weight range
Within acceptable weight range
Over acceptable weight range
Battery needs to be recharged
kg lb g Pcs
Current unit of measure
